Porsche Cayman 987 (2005-2009) hot at all times current distributor fuse Wiring diagram
This page shows the only wiring diagram for the component.hot at all times current distributor fuse, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times current distributor fuse (1 of 1)
1 2 RIGHT REAR HEATER R SEAT HEATER SPLY
25 26 LEFT REAR HEATER L SEAT HEATER SPLY
BLK WIRE
BRN WIRE
DRIVER SIDE
HOT AT ALL TIMES CURRENT DISTRIBUTOR FUSE
LEFT SEAT SIDE PAD HEATING ELEMENT
ONBOARD NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
PASSENGER SIDE
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/WHT WIRE
RIGHT SEAT SIDE PAD HEATING ELEMENT
SEAT BACKREST HEATING ELEMENT
SEAT CUSHIONS SIDE HEATING ELEMENT
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Heated seats circuit -> HOT AT ALL TIMES CURRENT DISTRIBUTOR FUSE
