Porsche Cayman 987 (2005-2009) front luggage compartment lock microswitch Wiring diagram
This page shows the only wiring diagram for the component.front luggage compartment lock microswitch, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front luggage compartment lock microswitch (1 of 1)
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
EMERGENCY LUGGAGE COMPARTMENT OPEN SWITCH
FRONT END CONTROL UNIT (AT RIGHT SIDE OF FRONT LUGGAGE COMPT)
FRONT HOOD
FRONT LUGGAGE COMPARTMENT LOCK MICROSWITCH
FRONT LUGGAGE/ REAR ENGINE COMPARTMENT HOOD SWITCH
FUSE HOLDER B (UNDER LEFT SIDE OF DASH, AT KICK PANEL) FUSE
HOT AT ALL TIMES
LUGGAGE COMPARTMENT HOOD DRIVE
ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
REAR CONTROL UNIT (UNDER DRIVER'S SEAT)
REAR HOOD
REAR HOOD LOCK MICROSWITCH
REAR HOOD MICRO SW TAILGATE UNLOCKING CAN COMFORT HIGH CAN COMFORT LOW
RED/BLK WIRE
RED/WHT WIRE
TAILGATE UNLOCKING DRIVE
TANK COVER DRIVE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Trunk, tailgate, fuel door circuit -> FRONT LUGGAGE COMPARTMENT LOCK MICROSWITCH
