Porsche Cayman 987 (2005-2009) driver power window switch Wiring diagram
This page shows the only wiring diagram for the component.driver power window switch, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver power window switch (1 of 1)
19 5 6 TERM 31 CAN HIGH CAN LOW
BLK WIRE
BLK/ORG WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL UNIT (IN LEFT DOOR)
DRIVER POWER WINDOW SWITCH
FRONT/ REAR CHANGE- OVER SWITCH
FUSE FUSE
FUSE HOLDER A (UNDER LEFT SIDE OF DASH, AT LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
LOWERING DOOR WINDOW SWITCH
PASSENGER DOOR CONTROL UNIT (IN RIGHT DOOR)
PASSENGER POWER WINDOW SWITCH
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
TERM 30 POWER WINDOW SYST
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Power windows circuit -> DRIVER POWER WINDOW SWITCH
