Porsche Cayman 987 (2005-2009) damptronic sw illum Wiring diagram

31 32 21 CAN HIGH DISPLAY CAN LOW DISPLAY DIM LED 35 38 IGNITION (POS II/III) LOW BEAM SW 5 35 37 38 SW INSIDE LT (BATT) INSIDE LT TERMINAL CAN HIGH CAN LOW 6 7 15 29 FRT LUGG COMPT LT CAN LOW CAN HIGH SIDE MARKER LT SW ASTRAY LIGHT BLK WIRE BLK/BLU WIRE BLK/RED WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE CENTRAL LOCKING SWITCH CIGAR LIGHTER COMPUTER DATA LINES CONNECTOR COMPUTER DATA LINES SYSTEM DAMPTRONIC SW ILLUM FRONT END CONTROL UNIT (AT RIGHT SIDE OF FRONT LUGGAGE COMPT) FRONT HOOD REAR HOOD FRONT LUGGAGE COMPARTMENT LIGHT FRONT LUGGAGE COMPARTMENT LOCK MICRO- SWITCH (FRONT OF FRONT LUGGAGE COMPT) FRONT LUGGAGE/ REAR ENGINE COMPARTMENT HOOD SWITCH FRT LUGG COMPT SW FUSE HOLDER C (UNDER LEFT SIDE OF DASH, AT LEFT KICK PANEL) FUSE GRN/ORG WIRE GRY WIRE GRY/RED WIRE HAZARD WARNING SWITCH HEADLIGHTS SYSTEM HOME LINK SWITCH 2 HOT W/ TERM 15 RELAY ENERGIZED ILLUM INSTRUMENT CLUSTER LIGHT SWITCH MIDDLE OUTLET LIGHTS ONBOARD NET WORK CONTROL MODULE (UNDER LEFT SIDE OF DASH) PSM SW ILLUM RED WIRE RIGHT OUTLET LIGHTS SPOILER SW ILLUM SPORT EXHAUST FLAP SW ILLUM SPORT SW ILLUM SWITCH MODULE WHT WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE YEL/WHT WIRE
