Porsche Cayman 987 (2005-2009) cls term 31 cls safe motor Wiring diagram
This page shows the only wiring diagram for the component.cls term 31 cls safe motor, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cls term 31 cls safe motor (1 of 1)
BLK/RED WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
CLS TERM 31 CLS SAFE MOTOR
COMPUTER DATA LINES SYSTEM
FUSE
FUSE HOLDER A (UNDER LEFT SIDE OF DASH, AT LEFT KICK PANEL)
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
LEFT DOOR CONTROL UNIT (IN LEFT DOOR)
LEFT DOOR LOCK
LEFT OUTSIDE DOOR HANDLE MICRO SWITCH
RED WIRE
RED/GRN WIRE
RIGHT DOOR CONTROL UNIT (IN RIGHT DOOR)
RIGHT DOOR LOCK
RIGHT OUTSIDE DOOR HANDLE MICRO SWITCH
VIO/BLK WIRE
YEL WIRE
Go to component -> Power door locks circuit (1 of 2) -> CLS TERM 31 CLS SAFE MOTOR
