Porsche Cayman 987 (2005-2009) can comfort high can comfort low back up light Wiring diagram
This page shows the only wiring diagram for the component.can comfort high can comfort low back up light, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can comfort high can comfort low back up light (1 of 1)
1 2 3 4 5 TERM 15 TERM 31 BACK UP SIGNAL ACTUATION + ACTUATION -
1 2 ANTI-DAZZLE MIRROR + ANTI-DAZZLE MIRROR -
A/T M/T
ANTI-DAZZLE INTERIOR MIRROR
BACK UP LIGHT SW CAN COMFORT HIGH CAN COMFORT LOW
BACK-UP LIGHT SWITCH (ON TOP RIGHT OF TRANSMISSION)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BRIDGE PLUG (RELAY SUPPORT 1)
BRN WIRE
BRN/WHT WIRE
CAN COMFORT HIGH CAN COMFORT LOW BACK UP LIGHT
COMPUTER DATA LINES SYSTEM
FUSE
FUSE HOLDER C (UNDER LEFT SIDE OF DASH, AT KICK PANEL)
GRN/BLK WIRE
HOT IN RUN OR START
MIRROR CONTROL UNIT
NCA WIRE
ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
REAR CONTROL UNIT (UNDER DRIVER'S SEAT)
YEL WIRE
YEL/BLK WIRE
Go to component -> Auto anti-dazzling mirror circuit -> CAN COMFORT HIGH CAN COMFORT LOW BACK UP LIGHT
