Porsche Cayman 987 (2005-2009) 22 12 7 6 term 58 operating sw - mirror adjustment mirror changeover sw Wiring diagram
This page shows the only wiring diagram for the component.22 12 7 6 term 58 operating sw - mirror adjustment mirror changeover sw, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 22 12 7 6 term 58 operating sw - mirror adjustment mirror changeover sw (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 ANTI-DAZZLE MIRROR + ANTI-DAZZLE MIRROR -
1 3 10 2 5 4 7 12 11 MIRROR POTI POS X
22 12 7 6 TERM 58 OPERATING SW - MIRROR ADJUSTMENT MIRROR CHANGEOVER SW
BLK WIRE
BLK/RED WIRE
BLU/BLK WIRE
BRN WIRE
DRIVER'S DOOR CONTROL UNIT
DRIVER'S MIRROR ADJUSMENT SWITCH
DRIVER'S MIRROR CONTROL UNIT
FUSE
GRN WIRE
HORI- ZONTAL
HOT AT ALL TIMES
LEFT
MIRROR HEATING
MIRRORS SYSTEM (ANTI-DAZZLE MIRROR CIRCUIT)
NCA WIRE
PASSENGER'S DOOR CONTROL UNIT
PASSENGER'S MIRROR CONTROL UNIT
RED/GRN WIRE
RED/WHT WIRE
RIGHT
TERM 30 POWER WINDOW
VERTICAL
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power mirror circuit -> 22 12 7 6 TERM 58 OPERATING SW - MIRROR ADJUSTMENT MIRROR CHANGEOVER SW
