Porsche Cayman 987 (2005-2009) 1 2 left fan + left fan - Wiring diagrams
This page contains all the electrical diagrams for the component. 1 2 left fan + left fan -, in which he is found in the car Porsche Cayman 987 (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 1 2 left fan + left fan - (1 of 2)
1 2 GND BATT
1 2 LEFT FAN + LEFT FAN -
1 2 RIGHT FAN + RIGHT FAN _
1 2 TERM 15 ACTUATION INPUT
27 25 36 37 A/C RELAY ENG COMPT BLWR RLY CAN HIGH CAN LOW
A/C COMPRESSOR
A/C COMPRESSOR RELAY (ON RELAY SUPPORT 2)
ACTUATION CONTROL UNIT TERM 15 FINAL STAGE
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BRN WIRE
CAN HIGH COMFORT
CAN LOW COMFORT
COMPUTER DATA LINES SYSTEM
COOLING WATER BLOWER CONTROL UNIT
CURRENT DISTRIBUTION
DMTL
ENGINE COMPARTMENT BLOWER (ON LEFT FRONT SIDE OF ENG COMPT)
ENGINE COMPARTMENT BLOWER RELAY (ON RELAY SUPPORT 2)
ENGINE CONTROLS, TRANSMISSION SYSTEMS
FRONT END CONTROL UNIT (AT RIGHT SIDE OF FRONT LUGGAGE COMPT)
FUSE
FUSE (UNDER LEFT SIDE OF DASH, AT LEFT KICK PANEL)
FUSE HOLDER B
FUSE HOLDER D (UNDER LEFT SIDE OF DASH, AT LEFT KICK PANEL)
GRN/WHT WIRE
HEATER RELAY (ON RELAY SUPPORT 1)
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE HOLDER F (LEFT REAR OF ENGINE COMPT) FUSE
HOT W/ MFI-DI RELAY ENERGIZED
LEFT RADIATOR FAN MOTOR
MAXI FUSE (FAN) (RIGH SIDE OF FRONT LUGGAGE COMPT)
MFI-DI CONTROL UNIT (ON LEFT SIDE OF REAR LUGGAGE COMPT)
NCA WIRE
ORG/ WIRE
PAS (DRIVER RECOGNITION) CONTROL UNIT (AT RIGHT KICK PANEL)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT RADIATOR FAN MOTOR
TERM 87
VIO/YEL WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> 1 2 LEFT FAN + LEFT FAN -
Wiring diagram 1 2 left fan + left fan - (2 of 2)
1 2 GND BATT
1 2 LEFT FAN + LEFT FAN -
1 2 RIGHT FAN + RIGHT FAN _
1 2 TERM 15 ACTUATION INPUT
ACTUATION CONTROL UNIT
BLK WIRE
BRN WIRE
CAN LOW COMFORT CAN HIGH COMFORT
COMPUTER DATA LINES SYSTEM
COOLING WATER BLOWER CONTROL UNIT
FRONT END CONTROL UNIT (AT RIGHT SIDE OF FRONT LUGGAGE COMPT)
HOT AT ALL TIMES
LEFT RADIATOR FAN MOTOR
MAXI FUSE (FAN) (RIGH SIDE OF FRONT LUGGAGE COMPT)
NCA WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RIGHT RADIATOR FAN MOTOR
TERM 15 FINAL STAGE
YEL WIRE
YEL/BLU WIRE
Go to component -> Cooling fan circuit -> 1 2 LEFT FAN + LEFT FAN -
