Porsche Cayman GT4 982 (2019-2024) lap trigger Wiring diagrams
This page contains all the electrical diagrams for the component. lap trigger, in which he is found in the car Porsche Cayman GT4 982 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram lap trigger (1 of 2)
4.0L TURBO
A/T
BLK WIRE
BRN WIRE
BRN/WHT WIRE
DIAGNOSTIC PLUG SOCKET
DRIVER'S DOOR CENTRAL LOCK SAFE LED
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR IGNITION LOCK LIGHT
DRIVER'S DOOR LOCK
DRIVER'S DOOR OUTER HANDLE SWITCH
DSRC CARD READER
ELECTRONIC IGNITION LOCK
EMERGENCY VOLTAGE SUPPLY RELAY 1
EPB BUTTON
FRONT BCM
FRONT PASSENGER DOOR CENTRAL LOCK SAFE LED
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER DOOR LOCK
FRONT PASSENGER OUTER DOOR HANDLE SWITCH
FRONT WIPER MOTOR
GATEWAY CONTROL UNIT
GLONASS CONTROL UNIT
GLOVE COMPARTMENT SWITCH
GRY WIRE
HEAD AIR BAG DS ESD GROUND
HEAD AIR BAG PS ESD GROUND
INSTRUMENT CLUSTER
KNEE AIR BAG DS ESD GROUND
KNEE AIR BAG PS ESD GROUND
LAP TRIGGER
LEFT FAN RELAY
LEFT FRONT FOOTWELL LIGHT
M/T
MAIN FUSE BOX
PAS PHANTOM ANTENNA 1 LUGGAGE COMPARTMENT
PASSENGER AIR BAG ESD GROUND
RIGHT END OF DASH)
RIGHT FAN RELAY
RIGHT FRONT FOOTWELL LIGHT
ROTARY LIGHT SWITCH
STEERING COLUMN ADJUSTMENT CONTROL UNIT
STEERING COLUMN LOCK
STEERING COLUMN SWITCHING MODULE
STOPWATCH
TWO-TONE HORNS RELAY
USB- HUB
WHT WIRE
WLAN CONTROL UNIT
Go to component -> Ground distribution circuit (2 of 5) -> LAP TRIGGER
Wiring diagram lap trigger (2 of 2)
