Porsche Cayman GT4 982 (2019-2024) hall sensor signal Wiring diagram
This page shows the only wiring diagram for the component.hall sensor signal, which is found in the car Porsche Cayman GT4 982 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hall sensor signal (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
CLOSE
CLOSING MOTOR
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP CONTROL UNIT
FUSE 3
FUSE 4
GRY/BLK WIRE
HALL SENSOR
HALL SENSOR GROUND
HALL SENSOR SIGNAL
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT E-HOOD MOTOR
LEFT FRONT FUSE BOX (ROW A)
LEFT HALL 1 MOTOR 1
LEFT MOTOR CLOSING
LEFT MOTOR OPENING
LIN
MOTOR
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
RED/GRY WIRE
RED/VIO WIRE
RIGHT E-HOOD MOTOR
RIGHT FRONT FUSE BOX (ROW C)
RIGHT HALL 1 MOTOR 2
RIGHT MOTOR 1 CLOSING +
RIGHT MOTOR 1 OPENING +
ROOF CONSOLE (IF EQUIPPED)
TERM 30
TERM 31
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/YEL WIRE
Go to component: -> Power top/sunroof circuit (1 of 2) -> HALL SENSOR SIGNAL
