Porsche Cayman GT4 981 (2015-2016) right rear tpm trigger module Wiring diagram

This page shows the only wiring diagram for the component.right rear tpm trigger module, which is found in the car Porsche Cayman GT4 981 (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram right rear tpm trigger module (1 of 1)

Wiring diagram right rear tpm trigger module for Porsche Cayman GT4 981 (2015-2016)

Get access

BLU WIRE BRN WIRE BRN/WHT WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM FL TRIGGER MOD SUPPLY FR TRIGGER MOD SUPPLY FUSE 5 GRN WIRE GROUND GRY WIRE HOT AT ALL TIMES LEFT FRONT TPM TRIGGER MODULE LEFT REAR TPM TRIGGER MODULE LR TRIGGER MOD SUPPLY ORG/BRN WIRE ORG/VIO WIRE RDK CONTROL UNIT RED/GRN WIRE RIGHT FRONT FUSE BOX (ROW B) RIGHT FRONT TPM TRIGGER MODULE RIGHT REAR TPM TRIGGER MODULE RR TRIGGER MOD SUPPLY SIGNAL SUPPLY TERM 30 TERM 31 TRIGGER MODULE GND TRIGGER MODULE SIGNAL WHT WIRE YEL WIRE
