Navigation circuit, w/ burmester for Porsche Cayenne III facelift (2023-2024)

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/VIO WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIGITAL SOUND PACKAGE AMPLIFIER FRONT ROOF MODULE MICROPHONE UNIT FUSE 1 FUSE 2 FUSE CARRIER 9 GRN WIRE GRN/VIO WIRE GROUND GRY WIRE GRY/VIO WIRE GRY/YEL WIRE HI RANGE CENTER LOUDSPEAKER - HOT AT ALL TIMES LEFT EFFECT LOUDSPEAKER LEFT EFFECT LOUDSPEAKER 2 LEFT FRONT BASS LOUDSPEAKER LEFT REAR BASS LOUDSPEAKER LEFT REAR MID-RANGE/ LOUDSPEAKER LEFT REAR TREBLE LOUDSPEAKER LF LO RANGE SPKR - LF MID-RANGE LOUDSPEAKER - LF TWEETER+ LH MID-RANGE LOUDSPEAKER - LR LO RANGE SPKR - LR LOW-RANGE SPEAKER + LR LOW-RANGE SPEAKER 1 LR MID-RANGE SPKR - LR TWEETER + LR WIDE BAND SPKR TWEETER - MICROPHONE SOUND MICROPHONE SOUND REC + MICROPHONE SOUND REC + (PINS: 25 TO 31 NOT USED) 32 MID-RANGE CENTER LOUDSPEAKER - N/A REAR FUSE BOX REC RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE REMOTE SUBWOOFER RF LO RANGE SPKR - RF MID-RANGE LOUDSPEAKER - RF TWEETER - RH HI RANGE LOUDSPEAKER + MID-RANGE CENTER LOUDSPEAKER + RH HI RANGE LOUDSPEAKER - RH MID-RANGE LOUDSPEAKER - RIGHT EFFECT LOUDSPEAKER RIGHT FRONT BASS LOUDSPEAKER RING BREAK DIAGNOSIS RR LO RANGE SPKR - RR MID-RANGE LOUDSPEAKER - RR MID-RANGE SPKR - RR TWEETER - RR WIDE-BAND SPKR - SUBWOOFER TERM 30 TERM 31 VIO WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE

BLK/YEL WIRE BLU/VIO WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE CENTER LOUDSPEAKER CENTER LOUDSPEAKER 2 GRN WIRE GRY WIRE GRY/VIO WIRE GRY/YEL WIRE LEFT FRONT ACTIVE WIDE BAND LOUDSPEAKER LEFT FRONT MID-RANGE LOUDSPEAKER LEFT FRONT TREBLE LOUDSPEAKER RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RIGHT EFFECT LOUDSPEAKER 2 RIGHT FRONT TREBLE LOUDSPEAKER WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE

BLK WIRE BLK/YEL WIRE BLU/VIO WIRE BLUETOOTH BLUETOOTH MOBILE PHONE COUPLING AERIAL BRN WIRE BRN/GRN WIRE BRN/WHT WIRE CAN HIGH MIB CAN LOW MIB COMPUTER DATA LINES SYSTEM FRONT RADIO CONTROLLED PARKING AERIAL 3 FUSE 11 FUSE 16 FUSE HOLDER J GROUND GRY/YEL WIRE HOT AT ALL TIMES N/A NCA WIRE ORG/BRN WIRE REAR FUSE BOX RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE LOUDSPEAKER RIGHT REAR ACTIVE WIDE BAND LOUDSPEAKER SHIELD SIG SIG - REMOTE SUBWOOFER SUBWOOFER TERM 30 TERM 31 VIO WIRE VIO/BLU WIRE VIO/YEL WIRE WHT WIRE

BLK WIRE BLUETOOTH BRN WIRE CAN HIGH CAN HIGH MIB CAN LOW CAN LOW MIB COMPUTER DATA LINES SYSTEM DASHBOARD FUSE BOX FLEXRAY BRANCH 1 BM FLEXRAY BRANCH 1 BP FRONT BLUETOOTH FUSE 1 FUSE 10 FUSE 14 FUSE 6 FUSE HOLDER F GRN WIRE GROUND HOT AT ALL TIMES LIN 2 MULTIMEDIA SYSTEM MULTIMEDIA SYSTEM OPERATING UNIT MULTIMEDIA SYSTEM OPERATING UNIT 2 N/A NCA WIRE ORG/BRN WIRE PNK WIRE RADIO CONTROLLED PARKING CONTROL UNIT REAR BLUETOOTH REAR RADIO CONTROLLED PARKING AERIAL 4 REAR WINDOW AERIAL 2 RED/GRY WIRE RED/YEL WIRE SATELLITE TUNER AERIAL SDARS SHIELD STEERING COLUMN ELECTRONICS CONTROL UNIT TERM 30 TERM 31 VIO WIRE VIO/WHT WIRE
