Porsche Cayenne III facelift (2023-2024) temp sens sun Wiring diagram
This page shows the only wiring diagram for the component.temp sens sun, which is found in the car Porsche Cayenne III facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram temp sens sun (1 of 1)
AIR CONDITIONER ACTR SPLY
AIR CONDITIONING SYSTEM CONTROL UNIT (CENTER OF DASH)
AIR CONDITIONING SYSTEM PRESSURE SWITCH
AIR QUALITY SENSOR
AIR RECIRCULATION FLAP CONTROL MOTOR
AUTOMATIC HEATER CONTROL INTERIOR SENSOR
BLK/BRN WIRE
BLOW-OUT TEMPERATURE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
EVAPORATOR TEMP SENS
FRESH AIR FLAP CONTROL MOTOR
FRONT FUSE BOX
FRONT TEMP SENS
FUSE 1
FUSE HOLDER D
GROUND ACTR CLIMATE
HOT W/
LEFT FOOTWELL)
LEFT FRONT POTI CENTER
LIN 1
LIN 2
LIN INPUT
LIN OUTPUT
REAR AIR QUANTITY CONTROL MOTOR
REAR TEMP SENS
RED WIRE
RED/BLU WIRE
RIGHT FOOTWELL FLAP CONTROL MOTOR
RIGHT FRONT SIDE POTI
RIGHT REAR AIR QUANTITY FLAP CONTROL MOTOR
RIGHT TEMPERATURE FLAP CONTROL MOTOR
SENS 1
SENS 2
SENS 3
SENS GROUND 1
SENSOR GROUND 2
SUPPLY ACTUATOR VEHICLE
SUPPLY RELAY
TEMP SENS SUN
TERM 15
TERM 30
TERM 31
TERMINAL 15 VOLTAGE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit (4 of 11) -> TEMP SENS SUN
