Porsche Cayenne III facelift (2023-2024) rear spoiler adjustment control unit Wiring diagram
This page shows the only wiring diagram for the component.rear spoiler adjustment control unit, which is found in the car Porsche Cayenne III facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear spoiler adjustment control unit (1 of 1)
3.0L TURBO HYBRID 4.0L TURBO HYBRID
ADAPTIVE SUSPENSION CONTROL UNIT
AUTOMATIC GEARBOX CONTROL UNIT
AXLE DIFFERENTIAL LOCK CONTROL UNIT
DIGITAL SOUND PACKAGE AMPLIFIER
FROM BATTERY ISOLATION UNIT (DIAGRAM 1 OF 9)
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE CARRIER 9
FUSE HOLDER G
FUSE HOLDER H
LEFT FRONT HEADLIGHT
LEFT REAR SEAT HEATING
N/A
REAR AIR CONDITIONING SYSTEM OPERATING, DISPLAY UNIT
REAR FUSE BOX
REAR LID POWER OPENING CONTROL UNIT
REAR SPOILER ADJUSTMENT CONTROL UNIT
REAR-END ELECTRONICS
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT HEADLIGHT
RIGHT REAR SEAT HEATING
TO FUSE CARRIER 8 (DIAGRAM 9 OF 9)
TO FUSE HOLDER J (DIAGRAM 8 OF 9)
TO FUSE HOLDER K (DIAGRAM 6 OF 9)
TO FUSE HOLDER Y (DIAGRAM 9 OF 9)
TO FUSE HOLDER Z (DIAGRAM 9 OF 9)
TRAILER DETECTOR CONTROL UNIT
W/ BURMESTER
Go to component -> Power distribution circuit (7 of 9) -> REAR SPOILER ADJUSTMENT CONTROL UNIT
