Porsche Cayenne III facelift (2023-2024) ground side marker light Wiring diagram
This page shows the only wiring diagram for the component.ground side marker light, which is found in the car Porsche Cayenne III facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground side marker light (1 of 1)
-MOUNTED
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BRAKE LIGHT SWITCH
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DASHBOARD FUSE BOX
ELECTRONIC IGNITION LOCK
FL PARKING LIGHT
FR PARKING LIGHT
FUSE 11
FUSE 14
FUSE HOLDER F
FUSE HOLDER J
GND (-) 31
GRN WIRE
GRN/GRY WIRE
GROUND
GROUND SIDE MARKER LIGHT
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/WHT WIRE
HIGH-LEVEL BRAKE LIGHT BULB
HOT AT ALL TIMES
LEFT FRONT DIRECTION INDICATOR PILOT LIGHT
LEFT TURN SIGNAL
LIGHT
LIN 1
MARKER LIGHT
ORG/BRN WIRE
POSITIVE
PROJECTION MODULES IN MATRIX HEADLIGHTS CONTROL UNIT
REAR FUSE BOX
RED/GRN WIRE
RIGHT FRONT DIRECTION INDICATOR PILOT LIGHT
RIGHT FRONT HEADLIGHT
RIGHT FRONT SIDE MARKER BULB
RIGHT FRONT TURN SIGNAL, SIDE LIGHT
RIGHT TAIL LIGHT
RIGHT TAIL LIGHT CLUSTER
RIGHT TURN SIGNAL
ROTARY LIGHT SWITCH
SPLY 30
STOP
STOP LIGHT/TURN SIG
TAILLIGHT
TRAILER DETECTOR CONTROL UNIT
TRAILER SOCKET
TURN SIGNAL
VIO/WHT WIRE
WHT/GRY WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> GROUND SIDE MARKER LIGHT
