Porsche Cayenne III facelift (2023-2024) adjustment up Wiring diagrams
This page contains all the electrical diagrams for the component. adjustment up, in which he is found in the car Porsche Cayenne III facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram adjustment up (1 of 2)
ADJUSTMENT
ADJUSTMENT DOWN
ADJUSTMENT MOTOR 1
ADJUSTMENT UP
BACKREST BACK
BACKREST FORWARD
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
FRONT FUSE BOX
FRONT HIGH SEAT TILT ADJUSTMENT
FRONT LOW SEAT TILT ADJUSTMENT
FUSE HOLDER S
GRN/RED WIRE
GROUND 31
GRY/BRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT BACKREST ADJUSTMENT MOTOR
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LEFT FRONT SEAT HEIGHT ADJUSTMENT MOTOR
LEFT FRONT SEAT LONGITUDINAL ADJUSTMENT MOTOR
LEFT FRONT SEAT RAKE ADJUSTMENT MOTOR
LEFT SEAT ADJUSTMENT CIRCUIT BREAKER
N/A
REAR SEAT DOWN
REAR SEAT UP
RED/BLK WIRE
SEAT BACK)
SEAT FORWARD
SEAT HEIGHT
SEAT RAKE
SEAT TILT
SUPPLY 30
WHT WIRE
WHT/RED WIRE
Go to component -> Driver power seat circuit -> ADJUSTMENT UP
Wiring diagram adjustment up (2 of 2)
ADJUSTMENT
ADJUSTMENT DOWN
ADJUSTMENT MOTOR 1
ADJUSTMENT UP
BACKREST BACK
BACKREST FORWARD
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
FRONT HIGH SEAT TILT ADJUSTMENT
FRONT LOW SEAT TILT ADJUSTMENT
FUSE HOLDER Z
GRN/RED WIRE
GROUND 31
GRY/BRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
N/A
REAR FUSE BOX
REAR SEAT DOWN
REAR SEAT UP
RED/BLK WIRE
RIGHT FRONT BACKREST ADJUSTMENT MOTOR
RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
RIGHT FRONT SEAT HEIGHT ADJUSTMENT MOTOR
RIGHT FRONT SEAT LONGITUDINAL ADJUSTMENT MOTOR
RIGHT FRONT SEAT RAKE ADJUSTMENT MOTOR
RIGHT SEAT ADJUSTMENT CIRCUIT BREAKER
SEAT BACK)
SEAT FORWARD
SEAT HEIGHT
SEAT RAKE
SEAT TILT
SUPPLY 30
WHT WIRE
WHT/RED WIRE
Go to component -> Front passenger power seat circuit -> ADJUSTMENT UP
