Porsche Cayenne III (2017-2023) right aerial Wiring diagrams
This page contains all the electrical diagrams for the component. right aerial, in which he is found in the car Porsche Cayenne III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right aerial (1 of 6)
AM/FM 1
AM/FM 1/DAB
ANTENNA
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLUETOOTH
BRN WIRE
CAN HIGH
CAN LOW
CAN MIB HIGH
CAN MIB LOW
CENTRAL
CENTRAL LOCKING SYSTEM (SHIELD) CENTRAL LOCKING SYSTEM (RADIO REMOTE CONTROL)
COMPUTER DATA LINES SYSTEM
DAB
DASH PANEL INSERT
DASHBOARD FUSE BOX
DIGITAL RADIO AERIAL
EXTERNAL AUDIO SOURCES INTERFACE
FM 2
FRONT BLUETOOTH
FRONT RADIO CONTROLLED PARKING AERIAL 3
FUSE 5
FUSE 8
FUSE HOLDER F
GPS
GPS AERIAL
GRN WIRE
GROUND
HOT AT ALL TIMES
LDVS 1 +
LDVS 2 OUT 1 +
LDVS 2 OUT 2 +
LDVS IN 1 -
LDVS IN 2 -
LEFT AERIAL
LOCKING,
LTE
LTE AERIAL 1
LTE AERIAL 2
LVDS 1 -
LVDS 2 -
MULTIMEDIA SYSTEM
MULTIMEDIA SYSTEM OPERATING, DISPLAY UNIT
N/A
NAVIGATION SYSTEM
ONBOARD SUPPLY CONTROL UNIT 2
ORG/ WIRE
ORG/BRN WIRE
RADIO CONTROLLED PARKING CONTROL UNIT
REAR BLUETOOTH
REAR RADIO CONTROLLED PARKING AERIAL 4
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT AERIAL
SHIELD
SYSTEM
TERM 30
TERM 31
USB DATA 1-
USB DATA 2+
VIO WIRE
WI-FI
WI-FI AERIAL
Go to component -> Base radio circuit (3 of 3) -> RIGHT AERIAL
