Porsche Cayenne III (2017-2023) gas suspension compressor Wiring diagrams
This page contains all the electrical diagrams for the component. gas suspension compressor, in which he is found in the car Porsche Cayenne III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram gas suspension compressor (1 of 2)
3.0L TURBO, 3.0L TURBO HYBRID
3.0L TURBO, 3.0L TURBO HYBRID 4.0L TURBO, 4.0L TURBO HYBRID
ADAPTIVE SUSPENSION CONTROL UNIT
ALL-WHEEL DRIVE CONTROL UNIT
ANTI-ROLL BAR CONTROL UNIT
AUTOMATIC GEARBOX CONTROL UNIT
BRAKE LIGHT SWITCH
BRN WIRE
CLUTCH ACTUATOR
CONNECTION 1, IN MAIN WIRING HARNESS
COOLANT PUMP FOR LOW- TEMPERATURE CIRCUIT 2
DRIVER ASSIST SYSTEMS CONTROL UNIT
EARTH CONNECTION, ON FUEL TANK FILLER NECK
ENGINE SOUND GENERATOR CONTROL UNIT 2
EXHAUST FLAP CONTROL UNIT
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER SIDE CENTRAL LOCKING LOCK UNIT
FRONT PASSENGER SIDE LIGHT FOR SILL PANEL MOULDING BACKGROUND LIGHTING
FUEL DELIVERY UNIT
FUEL PUMP CONTROL UNIT
GAS SUSPENSION COMPRESSOR
GEARBOX AUXILIARY HYDRAULIC PUMP
HEATED WINDSCREEM CONTROL UNIT
HIGH VOLTAGE BATTERY 1
MANUAL
POWER, CONTROL ELECTRONICS FOR ELECTRIC DRIVE
REFRIGERANT EXPANSION VALVE 2
RIGHT FRONT EXTERIOR DOOR HANDLE CONTACT SENSOR
RIGHT REAR SEAT HEATING CONTROL UNIT
WHT WIRE
Go to component -> Ground distribution circuit (3 of 6) -> GAS SUSPENSION COMPRESSOR
Wiring diagram gas suspension compressor (2 of 2)
BLU/YEL WIRE
BRN WIRE
CAN COMFORT HI
CAN COMFORT LO
CENTER CONSOLE FRONT CIGARETTE LIGHTER
COMPUTER DATA LINES SYSTEM
ELECT IGNITION LOCK SW 1
ELECT IGNITION LOCK SW 2
ELECT IGNITION LOCK SW 3
ELECT IGNITION LOCK SW 4
ELECTRIC TRAILER BRAKES POTENTIOMETER
ELECTRONIC IGNITION LOCK
FROM FUSE CARRIER 9 (DIAGRAM 7 OF 9)
FROM FUSE HOLDER H (DIAGRAM 7 OF 9)
FUSE 1
FUSE 2
FUSE CARRIER 8
FUSE HOLDER Y
FUSE HOLDER Z
GAS SUSPENSION COMPRESSOR
GRN WIRE
GRY/BLU WIRE
GRY/RED WIRE
HAZARD WARNING LIGHT SWITCH
HEATED REAR WINDOW RELAY
N/A
O/T RLY F PLUG SOCKETS
ONBOARD SUPPLY CONTROL UNIT
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT
RIGHT SEAT ADJUSTMENT CIRCUIT BREAKER
SIGNAL 1
SIGNAL 2
SIGNAL 3
SIGNAL 4
TERM 30
TERM 31
TERM 58 D
USB CHARGING SOCKET 1
WHT/GRY WIRE
YEL/GRY WIRE
Go to component -> Power distribution circuit (9 of 9) -> GAS SUSPENSION COMPRESSOR
