Porsche Cayenne II facelift (2014-2018) pipe frame servomotor Wiring diagrams

This page contains all the electrical diagrams for the component. pipe frame servomotor, in which he is found in the car Porsche Cayenne II facelift (2014-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram pipe frame servomotor (1 of 2)

Wiring diagram pipe frame servomotor for Porsche Cayenne II facelift (2014-2018)

Get access

ANGLE ADJ 1 ANGLE ADJ 2 BLU WIRE BLU/GRN WIRE BRN WIRE BRN/VIO WIRE BUTTON 1, 2 OFF CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DRIVER DOOR MEMORY BUTTON MODULE DRIVER'S DOOR CONTROL UNIT FORE, AFT ADJ 1 FORE, AFT ADJ 2 FUSE 16 GP-21 (LEFT KICK PANEL) GRN WIRE GRN/VIO WIRE GRY/RED WIRE HALL SENS HEIGHT ADJ 1 HEIGHT ADJ 2 HOT AT ALL TIMES LEFT FRONT FUSE BOX OFF FUN DISPLAY PIPE FRAME SERVOMOTOR RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SEAT DEPTH ADJ 1 SEAT DEPTH ADJ 2 SEAT DEPTH ADJUSTMENT MOTOR SET BUTTON SET FUN DISPLAY SUPPLY TERMINAL 31 VIO WIRE WHT WIRE WHT/YEL WIRE YEL WIRE

Go to component: -> Driver"s memory seat circuit (2 of 2) -> PIPE FRAME SERVOMOTOR

Wiring diagram pipe frame servomotor (2 of 2)

Wiring diagram pipe frame servomotor for Porsche Cayenne II facelift (2014-2018)

Get access

ANGLE ADJ 1 ANGLE ADJ 2 BLU WIRE BLU/GRN WIRE BRN WIRE BRN/VIO WIRE BUTTON 1, 2 OFF CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM FORE, AFT ADJ 1 FORE, AFT ADJ 2 FRONT PASSENGER DOOR CONTROL UNIT FRONT PASSENGER MEMORY BUTTON MODULE FUSE 11 GP-20 (RIGHT KICK PANEL) GRN WIRE GRN/VIO WIRE GRY/RED WIRE HALL SENS HEIGHT ADJ 1 HEIGHT ADJ 2 HOT AT ALL TIMES OFF FUN DISPLAY PIPE FRAME SERVOMOTOR RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT END OF DASH) RIGHT FRONT FUSE BOX SEAT DEPTH ADJ 1 SEAT DEPTH ADJ 2 SEAT DEPTH ADJUSTMENT MOTOR SET BUTTON SET FUN DISPLAY SUPPLY TERMINAL 31 VIO WIRE WHT WIRE WHT/YEL WIRE YEL WIRE

Go to component: -> Passenger"s memory seat circuit (2 of 2) -> PIPE FRAME SERVOMOTOR
