Porsche Cayenne II facelift (2014-2018) lr interior light, reading light Wiring diagram
This page shows the only wiring diagram for the component.lr interior light, reading light, which is found in the car Porsche Cayenne II facelift (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lr interior light, reading light (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 54
GP-21
GRN WIRE
GRY WIRE
HANDS-FREE MICROPHONE -
LIN
LR INTERIOR LIGHT, READING LIGHT
LR READING LIGHT
MICROPHONE SHIELD
MICROPHONE SIGNAL
REAR LIGHT GROUND
REAR ORIENTATION LIGHT
REAR SYMBOL LIGHTING
RED WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT FRONT FUSE BOX
ROOF CONSOLE
RR INTERIOR LIGHT, READING LIGHT
RR READING LIGHT
SOUND SYSTEMS
TERM 30 TRANSPORT
TERM 31
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRY WIRE
Go to component: -> Overhead console circuit -> LR INTERIOR LIGHT, READING LIGHT
