Porsche Cayenne II facelift (2014-2018) adjustment btn gnd Wiring diagrams

This page contains all the electrical diagrams for the component. adjustment btn gnd, in which he is found in the car Porsche Cayenne II facelift (2014-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram adjustment btn gnd (1 of 2)

Wiring diagram adjustment btn gnd for Porsche Cayenne II facelift (2014-2018)

Get access

ADJUSTMENT BTN GND ADJUSTMENT BTN SIG ADJUSTMENT CODED BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE BUTTON COMPUTER DATA LINES SYSTEM FUSE 7 GP-21 GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE HALL SENS HALL SENS FORE/AFT + HALL SENS HEIGHT + HOT W/ LEFT FRONT FUSE BOX LIN MOTOR MOTOR + UP MOTOR +FORE/AFT RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED STEERING COLUMN ADJUSTMENT CONTROL UNIT STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN FORE/AFT ADJUSTMENT MOTOR STEERING COLUMN HEIGHT ADJUSTMENT MOTOR TERM 30 TERM 31 VIO/WHT WIRE

Go to component: -> Power tilt steering column circuit -> ADJUSTMENT BTN GND

Wiring diagram adjustment btn gnd (2 of 2)

Wiring diagram adjustment btn gnd for Porsche Cayenne II facelift (2014-2018)

Get access

ADJUSTMENT BTN GND ADJUSTMENT BTN SIG ADJUSTMENT CODED BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE BUTTON BUTTON 1, 2 OFF CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DRIVER DOOR MEMORY BUTTON MODULE FUSE 16 FUSE 7 GP-21 GP-21 (LEFT KICK PANEL) GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE HALL SENS HALL SENS FORE/AFT + HALL SENS HEIGHT + HOT AT ALL TIMES HOT W/ LEFT FRONT FUSE BOX LIN MOTOR MOTOR + UP MOTOR +FORE/AFT OFF FUN DISPLAY RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED SET BUTTON SET FUN DISPLAY STEERING COLUMN ADJUSTMENT CONTROL UNIT STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN FORE/AFT ADJUSTMENT MOTOR STEERING COLUMN HEIGHT ADJUSTMENT MOTOR SUPPLY TERM 30 TERM 31 TERMINAL 31 VIO/WHT WIRE WHT WIRE YEL WIRE

Go to component: -> Steering column memory circuit -> ADJUSTMENT BTN GND
