Porsche Cayenne II (2010-2014) thrtl vlv gnd dve potn gnd wiring diagram
This page shows the only wiring diagram for the component.thrtl vlv gnd dve potn gnd, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
thrtl vlv gnd dve potn gnd wiring diagram (1 of 1)
3.0L HYBRID
3.0L HYBRID 3.6L, 4.8L 3.6L, 4.8L
3.6L
3.6L 3.0L HYBRID 4.8L 1 1 2 2 3 3
3.6L, 4.8L
42 34 15 CAN HIGH CAN LOW TERM 31
ACL VLU 2
ACTL VLU 1 PDL VLU SNSR
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE PEDAL SWITCH (TOP OF BRAKE PEDAL)
BRN WIRE
BRN/BLK WIRE
CAN DR HI
CAN DR LO
CLUTCH SENSOR (M/T)
CLUTCH SW
COMPUTER DATA LINES SYSTEM
DME CONTROL UNIT (RIGHT REAR ENGINE COMPT)
DVE POTN 1
E-BOX (LEFT SIDE OF PLENUM)
FUSE 10
FUSE 15
GND PTNOMTR 2 PDL VLU SNSR
GP-21 (LEFT KICK PANEL)
GP-40 (NEAR RIGHT TAILLIGHT)
GRA
GRN WIRE
HOT AT ALL TIMES LEFT FRONT FUSE BOX FUSE 19 (LEFT SIDE OF DASH)
HOT W/ MAIN RELAY 1 ENERGIZED
INTER LK
MTR
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PDL VLU SESR SIG 2
PDL VLU SNSR
PDL VLU SNSR ACTL VLU 1
PDL VLU SNSR ACTL VLU 2
PDL VLU SNSR GND PTNOMTR 1
PDL VLU SNSR GND PTNOMTR 2
PEDAL VALUE SENSOR
REAR BCM CONTROL UNIT (RIGHT SIDE OF REAR COMPT)
RED/GRN WIRE
RED/YEL WIRE
SIG
SIG (+) SIG 1
SIG - GND POTI
SIG TERM 87 BRAKE SIG
STOP LIGHT SWITCH
TERM 30
THROTTLE VALVE UNIT
THRTL VLV ACTL 1 DVE POTN 1
THRTL VLV ACTL 2 DVE POTN 2
THRTL VLV GND DVE POTN GND
THRTL VLV MTR - DVE MTR -
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Cruise control circuit -> THRTL VLV GND DVE POTN GND
