Porsche Cayenne II (2010-2014) signal supply ground wiring diagram
This page shows the only wiring diagram for the component.signal supply ground, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
signal supply ground wiring diagram (1 of 1)
1 2 3 4 GROUND SIGNAL SUPPLAY
1 2 3 4 GROUND SUPPLY SIGNAL
1 2 3 4 SIGNAL SUPPLY GROUND
BLU WIRE
BRN WIRE
CAN HIGH CAN LOW FL SUPPLY RL SUPPLY PWM DATA TRIM 31
COMPUTER DATA LINES SYSTEM
FUSE 8 (LEFT SIDE OF DASH)
GP-31 (BASE OF LEFT "B" PILLAR)
HOT W/ TERMINAL
LEFT FRONT TPM TRIGGER MODULE
LEFT FUSE BOX
LEFT REAR TPM TRIGGER MODULE
ORG/BRN WIRE
ORG/VIO WIRE
PWM GROUND FR SUPPLY RR SUPPLY
RDK CONTROL UNIT (NEAR BASE OF LEFT "B" PILLAR)
RED/BRN WIRE
RIGHT FRONT TPM TRIGGER MODULE
RIGHT REAR TRIGGER MODULE
SIGNAL SUPPLY GROUND
YEL WIRE
Go to component -> Warning systems circuit -> SIGNAL SUPPLY GROUND
