Porsche Cayenne II (2010-2014) right rear out side door handle switch Wiring diagram
This page shows the only wiring diagram for the component.right rear out side door handle switch, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear out side door handle switch (1 of 1)
BRN WIRE
DRIVER SEAT ADJUSTMENT OUTPUT CONTROL UNIT
DRIVER SEAT BACKREST VENTILATION MOTOR
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER SEAT SEAT FOOTWELL CONTROL LIGHT UNIT
FRONT PASSENGER'S SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER'S SEAT FOOTWELL LIGHT
FUEL PUMP SYSTEM CONTROL UNIT
GP-28 (RIGHT END OF DASH)
GP-30 (BASE OF RIGHT "B" PILLAR)
GP-31 (BASE OF LEFT "B" PILLAR)
GP-34 (RIGHT FRONT OF REAR COMPT)
LEFT FRONT REAR SEAT ENTERTAINMENT
LEFT FRONT SEAT BACKREST HEATING ELEMENT
LEFT REAR DOOR CONTROL UNIT
LEFT REAR DOOR SILL LIGHTING
LEFT REAR LEFT FRONT SEAT SEAT CUSHION CUSHION HEATING HEATING ELEMENT ELEMENT
LEFT REAR OUT SIDE DOOR LEFT REAR HANDLE DOOR LOCK SWITCH SLOT
MAIN FUSE BOX
PCM
PDK CONTROL UNIT
RADIO, AMPLIFIER
REAR DIFFERENTIAL LOCK CONTROL UNIT
RIGHT FRONT LEFT FRONT DOOR SILL DOOR SILL LIGHTING LIGHTING
RIGHT FRONT SEAT BACKREST HEATING ELEMENT
RIGHT FRONT SEAT CUSHION HEATING ELEMENT
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR DOOR LOCK SLOT
RIGHT REAR DOOR SILL LIGHTING
RIGHT REAR OUT SIDE DOOR HANDLE SWITCH
RIGHT REAR SEAT CUSHION HEATING ELEMENT
SUPER CHARGER LEVEL CONTROL
TANK SYSTEM
TO GP-26 (DIAGRAM 4 OF 6)
TRANSMISSION OIL PUMP DRIVER
W/ MEMORY
WHT WIRE
Go to component -> Ground distribution circuit (5 of 6) -> RIGHT REAR OUT SIDE DOOR HANDLE SWITCH
