Porsche Cayenne II (2010-2014) right front outer door handle switch Wiring diagrams

5 2 1 6 4 3 LIN ELV ENABLE TERM 15 TERM 30 ELV MOTOR SUPPLY TERM 31 BLK/BLU WIRE BLK/RED WIRE BLU/GRN WIRE BLU/YEL WIRE BRN BRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CLOSE BUTTON COMPUTER DATA LINES LINES SYSTEM COMPUTER DATA LINES SYSTEM ELV DRIVE LINK SUPPLY ENABLE TERM 15 FRONT BCM (LEFT SIDE OF DASH) FRONT PASSENGER'S DOOR CONTROL UNIT GP-20 (RIGHT KICK PANEL) GP-21 (LEFT KICK PANEL) GP-23 (LEFT SIDE OF DASH) GP-30 (BASE OF RIGHT "B" PILLAR) GRN/YEL WIRE GRY WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT FUSE BOX FUSE 22 (LEFT SIDE OF DASH) LEFT FRONT OUTER DOOR HANDLE ELECTRONICS LEFT FRONT OUTER DOOR HANDLE SWITCH LEFT REAR OUTER DOOR HANDLE ELECTRONICS LIN 3 ORG/BRN WIRE ORG/GRN WIRE PASSENGER DOOR LOCK RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT OUTER DOOR HANDLE SENSOR RIGHT FRONT OUTER DOOR HANDLE SWITCH RIGHT REAR OUTER DOOR HANDLE SENSOR RIGHT REAR OUTER DOOR HANDLE SWITCH STEERING COLUMN LOCK SUPPLY TERM 30 TERM 31 VIO WIRE VIO/GRN WIRE VIO/RED WIRE VIO/YEL WIRE WAKEUP DR CTRL UNIT WHT WIRE WHT/VIO WIRE YEL/RED WIRE

5 2 1 6 4 3 LIN ELV ENABLE TERM 15 TERM 30 ELV MOTOR SUPPLY TERM 31 BLK/BLU WIRE BLK/RED WIRE BLU/GRN WIRE BLU/YEL WIRE BRN BRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CLOSE BUTTON COMPUTER DATA LINES LINES SYSTEM COMPUTER DATA LINES SYSTEM ELV DRIVE LINK SUPPLY ENABLE TERM 15 FRONT BCM (LEFT SIDE OF DASH) FRONT PASSENGER'S DOOR CONTROL UNIT GP-20 (RIGHT KICK PANEL) GP-21 (LEFT KICK PANEL) GP-23 (LEFT SIDE OF DASH) GP-30 (BASE OF RIGHT "B" PILLAR) GRN/YEL WIRE GRY WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT FUSE BOX FUSE 22 (LEFT SIDE OF DASH) LEFT FRONT OUTER DOOR HANDLE ELECTRONICS LEFT FRONT OUTER DOOR HANDLE SWITCH LEFT REAR OUTER DOOR HANDLE ELECTRONICS LIN 3 ORG/BRN WIRE ORG/GRN WIRE PASSENGER DOOR LOCK RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT OUTER DOOR HANDLE SENSOR RIGHT FRONT OUTER DOOR HANDLE SWITCH RIGHT REAR OUTER DOOR HANDLE SENSOR RIGHT REAR OUTER DOOR HANDLE SWITCH STEERING COLUMN LOCK SUPPLY TERM 30 TERM 31 VIO WIRE VIO/GRN WIRE VIO/RED WIRE VIO/YEL WIRE WAKEUP DR CTRL UNIT WHT WIRE WHT/VIO WIRE YEL/RED WIRE
