Porsche Cayenne II (2010-2014) right front driver side sensor rear belt tensioner Wiring diagram
This page shows the only wiring diagram for the component.right front driver side sensor rear belt tensioner, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front driver side sensor rear belt tensioner (1 of 1)
AIR BAG CONTROL UNIT (UNDER CENTER CONSOLE)
AIR BAG TRIGGERING
BELT TENSIONER - BELT TENSIONER +
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
CAN DIAGNOSTIC HI
CAN DIAGNOSTIC LO
CAN-HIGH CAN-LOW
COMPUTER DATA LINES SYSTEM
DIAGNOSTIC PLUG SOCKET
DRIVER - DRIVER + BATT + BATT -
DRIVER KNEE AIR BAG
DRIVER SIDE REAR THORAX AIR BAG
DRIVER'S DOOR PRESSURE SENSOR
ESD GND
ESD GND NETWORK
FRONT PASSENGER DOOR PRESSURE SENSOR
FRONT PASSENGER SIDE REAR BELT TENSIONER
GRN WIRE
GRY WIRE
LEFT FRONT SENSOR
LEFT REAR WHEEL HOUSING SIDE IMPACT SENSOR
NEGATIVE
OCCUPANCY DETECTION PASSENGER + PASSENGER -
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRY WIRE
PASSENGER SIDE REAR THORAX AIR BAG
POSITIVE
PYROTECHNICAL BATT + PYROTECHNICAL BATT - TERM 15
RED WIRE
RIGHT FRONT BELT BUCKLE
RIGHT FRONT DRIVER SIDE SENSOR REAR BELT TENSIONER
RIGHT REAR WHEEL HOUSING SIDE IMPACT SENSOR
SIG
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> RIGHT FRONT DRIVER SIDE SENSOR REAR BELT TENSIONER
