Porsche Cayenne II (2010-2014) rear center console plug rain socket 1 sensor Wiring diagram
This page shows the only wiring diagram for the component.rear center console plug rain socket 1 sensor, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear center console plug rain socket 1 sensor (1 of 1)
A/C COMPRESSOR VALVE +
ANTI-DAZZLE INTERIOR MIRROR
BRAKE BOOSTER
BRAKE ROOF FLUID CONSOLE SENSOR
BRN WIRE
DC/DC CONVERTER 1
DIAGNOSTIC PLUG SOCKET
DRIVER DOOR LOCK SLOT
DRIVER'S DOOR CENTRAL LOCK SAFE LED
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR OUT SIDE DOOR HANDLE SWITCH
FROM PARK ASSIST CONTROL UNIT (DIAGRAM 3 OF 6)
FRONT PASSENGER'S DOOR CENTRAL LOCK SAFE LED
FRONT PASSENGER'S DOOR CONTROL UNIT
FRONT PASSENGER'S DOOR LOCK SLOT
FRONT PASSENGER'S DOOR OUTER DOOR HANDLE SWITCH
FRONT PASSENGER'S FOOTWELL PLUG SOCKET
GATEWAY CONTROL UNIT
GLASS ROOF BLIND MOTOR
GLASS ROOF I MOTOR
GP-20 (RIGHT KICK PANEL)
GP-21 (LEFT KICK PANEL)
GP-FSH LL (LEFT SIDE OF OF CENTER CONSOLE)
GP-FSH RE (RIGHT SIDE OF CENTER CONSOLE)
HEATED WINDSHIELD
HOMELINK CONTROL PARK ASSIST UNIT CONTROL UNIT
LEFT FRONT FOOTWELL LIGHT
REAR CENTER CONSOLE PLUG RAIN SOCKET 1 SENSOR
RIGHT FRONT FOOTWELL LIGHT
ROTARY CAN LIGHT DISTRIBUTOR SWITCH
SLIDING ROOF DRIVE
STEERING COLUMN ADJUSTMENT CONTROL UNIT
STEERING COLUMN SWITCHING MODULE
STOP LIGHT SWITCH
TO GP-21 (DIAGRAM 3 OF 6)
TO GP-22 (DIAGRAM 4 OF 6)
WHT WIRE
Go to component -> Ground distribution circuit (3 of 6) -> REAR CENTER CONSOLE PLUG RAIN SOCKET 1 SENSOR
