Porsche Cayenne II (2010-2014) porsche left front seat Wiring diagram
This page shows the only wiring diagram for the component.porsche left front seat, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram porsche left front seat (1 of 1)
AUDIO 1 GND
AUDIO 1 L
AUDIO 1 R
AUDIO 2 GND
AUDIO 2 L
AUDIO 2 R
AUDIO GND
AUDIO L+
AUDIO R-
AUDIO SHIELD
BLK WIRE
BLU WIRE
BRN WIRE
ENTERTAINMENT MODULE
FUSE 40
GP-22 (RIGHT SIDE OF DASH)
GRN WIRE
GRY WIRE
HOT W/ PLUG SOCKETS RELAY ENERGIZED
PORSCHE LEFT FRONT SEAT
PORSCHE RIGHT FRONT SEAT ENTERTAINMENT MODULE
RED/YEL WIRE
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
TELEVISION TUNER (RIGHT SIDE OF CARGO AREA)
TERM 30
TERM 30 TERM 31
TERM 31
VIDEO 1 GND
VIDEO 1 SIG
VIDEO 2 GND
VIDEO 2 SIG
VIDEO GND
VIDEO SIGNAL
VIO WIRE
W/ TV TUNER W/O TV TUNER
WHT WIRE
YEL WIRE
Go to component -> Rear seat entertainment circuit -> PORSCHE LEFT FRONT SEAT
