Porsche Cayenne II (2010-2014) plg button Wiring diagram
This page shows the only wiring diagram for the component.plg button, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram plg button (1 of 1)
1 2 CAN COMFORT HIGH CAN COMFORT LOW
2 1 3 4 LIGHT REDUNDANT LIN TERM 30 LF SIDE MARKER LIGHT
A/C CONTROL UNIT
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
COMBINED STEERING COLUMN MODULE
COMPUTER DATA LINES SYSTEM
FRONT BCM (LEFT SIDE OF DASH)
FUSE
GP-21 (LEFT KICK PANEL)
GP-22 (RIGHT SIDE OF DASH)
GP-41 (NEAR LEFT TAILLIGHT)
GP-44 (W/ RIGHT REAR FLAP) (LOWER RIGHT SIDE OF LIFTGATE)
GP-5 (LEFT FRONT OF ENGINE COMPT)
GP-6 (RIGHT FRONT OF ENGINE COMPT)
GRN/WHT WIRE
GRY WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
HOT W/ TERMINAL 15 RELAY ENERGIZED
LEFT FUSE BOX (LEFT SIDE OF DASH)
LEFT REAR LID WARNING LIGHT
LEFT SIDE TURN SIGNAL
LEFT TAIL LIGHT ASSEMBLY
LT SW
ORG/BRN WIRE
ORG/GRN WIRE
PLG BUTTON
RED/YEL WIRE
RIGHT REAR LID WARNING LIGHT
RIGHT SIDE TURN SIGNAL
ROTARY LIGHT SWITCH
TERM
TERM 31
VIO/GRN WIRE
WIPER/WASHER SYSTEM
YEL WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> PLG BUTTON
