Porsche Cayenne II (2010-2014) pao switch l 2 Wiring diagram
This page shows the only wiring diagram for the component.pao switch l 2, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pao switch l 2 (1 of 1)
1 2 3 4 5 6 7 8 9 10 GND PASS SEAT POS
AIR BAG 1-
AIR BAG 2+
AIR BAG CONTROL UNIT (UNDER CENTER CONSOLE)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN COMFORT HI
CAN COMFORT LO
COMPUTER DATA LINES SYSTEM
DRIVER BELT TENSIONER
DRIVER HEAD AIR BAG
DRIVER'S BUCKLE
FORCE LIMITER, DRIVER -
FORCE LIMITER, PASS+
FUSE
GRN WIRE
GRY WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED
LEFT FRONT BELT BUCKLE
NEGATIVE
ORG/BRN WIRE
ORG/GRN WIRE
PAO SWITCH L 2
PASSENGER
PASSENGER + FORCE LIMITER
PASSENGER BELT TENSIONER
PASSENGER HEAD AIR BAG
PASSENGER KNEE AIR BAG
POSITIVE
PRETENSIONER
RED WIRE
RIGHT FRONT FUSE BOX (RIGHT SIDE OF DASH)
RIGHT FRONT SEAT POSITION SENSOR
SIG
STEERING COLUMN SWITCHING MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> PAO SWITCH L 2
