Porsche Cayenne II (2010-2014) maxi fuse 57 Wiring diagrams
This page contains all the electrical diagrams for the component. maxi fuse 57, in which he is found in the car Porsche Cayenne II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram maxi fuse 57 (1 of 2)
CHASSIS CONTROL SWITCH
DRIVER'S DRIVER'S SEAT SEAT ADJUSTMENT CONTROL OPTIONAL UNIT CONTROL UNIT
FRESH AIR FAN MOTOR
FROM MAIN FUSE BOX, FUSE 1 (DIAGRAM 1 OF 8)
FROM MAIN FUSE BOX, FUSE 7 (DIAGRAM 1 OF 8)
FROM RIGHT FUSE BOX, FUSE 46
FRONT WIPER MOTOR
FUSE
FUSE 11 FUSE FUSE 12
FUSE 13
FUSE 34 FUSE FUSE 35
FUSE 36
FUSE FUSE
FUSE FUSE FUSE FUSE
FUSE FUSE FUSE FUSE FUSE
GLASS ROOF BLIND MOTOR
GLASS ROOF STEERING MOTOR 1 COLUMN ADJUSTMENT CONTROL UNIT
LEFT FUSE BOX (LEFT
LEFT HEATED WINDSHIELD RELAY
MAXI FUSE 57
MOBILE PHONE CHARGING TRAY
PARKING HEATER CONTROL UNIT
PDCC PASM CONTROL CONTROL UNIT UNIT
RAIN SENSOR
RDK CONTROL UNIT
REAR BCM
REAR BRAKE DIFFERENTIAL BOOSTER LOCK CONTROL UNIT
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT BLUETOOTH CHARGING TRAY
RIGHT FUSE BOX (RIGHT
RIGHT HEATED WINDSHIELD RELAY
SIDE OF DASH)
SLIDING ROOF DRIVE
SUBWOOFER (W/ BOSE)
SUBWOOFER (W/ BURMESTER)
TRAILER HITCH CONTROL UNIT
W/ W/O MEMORY MEMORY TWO-TONE HORNS RELAY
WHT/RED WIRE
Go to component -> Power distribution circuit (4 of 8) -> MAXI FUSE 57
Wiring diagram maxi fuse 57 (2 of 2)
4.8L, 4.8L TWIN TURBO
ALARM SIREN
ALL-WHEEL DRIVE CONTROL UNIT
COMPRESSOR RELAY
DIAGNOSTIC PLUG SOCKET
DME CONTROL UNIT
DRIVER'S DOOR CONTROL UNIT
ENGINE LID SWITCH
EPB CONTROL UNIT
FROM MAIN FUSE BOX, FUSE 4 (DIAGRAM 1 OF 8)
FROM MAIN FUSE BOX, FUSE 9 (DIAGRAM 1 OF 8)
FRONT BCM
FRONT BCM 3.6L
FUSE
FUSE 24
FUSE 25
FUSE 45
FUSE 54 SIDE OF DASH)
FUSE FUSE
GATEWAY CONTROL UNIT
LEFT FUSE BOX (LEFT SIDE OF DASH)
LEFT HEATED WINDSHIELD RELAY
MAXI FUSE 56
MAXI FUSE 57
PSM ALL-WHEEL CONTROL DRIVE UNIT CONTROL UNIT
PSM CONTROL UNIT
REAR LUGGAGE COMPARTMENT LIGHT
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FUSE BOX (RIGHT
RIGHT HEATED WINDSHIELD RELAY
RIGHT REAR FRONT DOOR PASSENGER DOOR CONTROL UNIT CONTROL UNIT
ROOF CONSOLE
ROTARY LIGHT SWITCH
STEERING COLUMN LOCK
TO DC/DC CONVERTER (DIAGRAM 8 OF 8)
TO DC/DC CONVERTER 1 (DIAGRAM 8 OF 8)
TO ELECTRONIC IGNITION LOCK (DIAGRAM 1 OF 8)
TRANSMISSION CONTROL UNIT
TRANSMISSION OIL PUMP RELAY (HYBRID)
TRANSMISSION OIL PUMP RELAY (W/ START/ STOP)
WHT WIRE
YEL/WHT WIRE
Go to component -> Power distribution circuit (5 of 8) -> MAXI FUSE 57
