Porsche Cayenne II (2010-2014) left right battery battery fan fan Wiring diagram
This page shows the only wiring diagram for the component.left right battery battery fan fan, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left right battery battery fan fan (1 of 1)
3.0L HYBRID
BACKUP CAMERA CONTROL UNIT
BCM
BLU WIRE
BRN WIRE
BRN/WHT WIRE
EPB CONTROL UNIT
FUEL FILLER NECK GROUND
GP-40 (NEAR RIGHT TAIL LIGHT)
GP-41 (NEAR LEFT TAIL LIGHT)
GP-42 (W/ RIGHT REAR FLAP) (CENTER REAR OF ROOF)
GP-44 (W/ RIGHT REAR FLAP) (LOWER RIGHT SIDE OF LIFTGATE)
GP-45 (W/ LEFT REAR FLAP) (TOP LEFT SIDE OF LIFTGATE)
GP-46 (RIGHT SIDE OF REAR COMPT)
HIGH MOUNTED STOP LIGHT
HIGH VOLTAGE BATTERY SYSTEM
LEFT FRONT HEIGHT SENSOR
LEFT HEADLIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR HEIGHT SENSOR
LEFT RIGHT BATTERY BATTERY FAN FAN
LEFT TAIL LIGHT ASSEMBLY
MASTER LANE CHANGE REAR FAN ASSISTANT MOTOR
PASM CONTROL UNIT
POWER LIFTGATE CONTROL UNIT
REAR LEFT WINDOW REAR LID MODULE WARNING LIGHT
REAR LID HANDLE OPENER
REAR WINDOW BLOCKING CIRCUIT
RIGHT LICENSE PLATE LIGHT
RIGHT PLG REAR LID BUTTON WARNING LIGHT
RIGHT REAR TAIL LIGHT UNIT LID
RIGHT REAR WINDOW BLOCKING CIRCUIT
RIGHT TAIL LIGHT ASSEMBLY
SLAVE LUGGAGE LANE COMPARTMENT CHANGE SOCKET ASSISTANT
SUB-WOOFER
TAILGATE LOCK MOTOR
TELEVISION AMPLIFIER TUNER
TRAILER HITCH CONTROL UNIT
TRAILER SOCKET 1
TRAILER SOCKET 2
TRAILER SOCKET 3
W/ DRIVE SWITCH W/O DRIVE SWITCH
W/O BOSE W/ BOSE
WHT WIRE
Go to component -> Ground distribution circuit (6 of 6) -> LEFT RIGHT BATTERY BATTERY FAN FAN
