Porsche Cayenne II (2010-2014) lane change assistant slave Wiring diagram
This page shows the only wiring diagram for the component.lane change assistant slave, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lane change assistant slave (1 of 1)
3.0L HYBRID
AIR QUALITY SENSOR
ANTI-DAZZLE INTERIOR MIRROR
AUTOMATIC TRANSMISSION
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER'S SEAT BACKREST VENT MOTOR
ELECTRIC A/C COMPRESSOR
ELECTRONIC POWER DRIVE
EPB PSM CONTROL CONTROL UNIT UNIT
FROM MAIN FUSE BOX, TERMINAL 15 RELAY (DIAGRAM 1 OF 8)
FRONT PASSENGER SEAT BACKREST VENT MOTOR
FRONT PASSENGER SEAT CUSHION VENTILATION MOTOR
FUSE
FUSE 43 FUSE
FUSE 44
FUSE 46 FUSE 51 FUSE 52
FUSE 53
FUSE 54
FUSE FUSE
FUSE FUSE FUSE
LANE CHANGE ASSISTANT SLAVE
LANE CHANGE REAR ASSISTANT WINDOW MASTER MODULE
LEFT FUSE BOX (LEFT SIDE OF DASH)
LEFT HEADLIGHT
LEFT TAIL LIGHT ASSEMBLY
PDCC CONTROL UNIT
POWER STEERING PUMP
RED/GRN WIRE
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
RIGHT HEADLIGHT
SPINDLE ACTUATOR
STEERING COLUMN SWITCHING MODULE
SUN RIGHT SENSOR TAILLIGHT ASSEMBLY
TO LEFT FUSE BOX, FUSE 47 (DIAGRAM 7 OF 8)
TO PLENUM PANEL FUSE BOX, FUSE 1 (DIAGRAM 2 OF 8)
TRANSMISSION CONTROL UNIT RIGHT HEADLIGHT
VIO WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (6 of 8) -> LANE CHANGE ASSISTANT SLAVE
