Porsche Cayenne II (2010-2014) jump start point Wiring diagrams
This page contains all the electrical diagrams for the component. jump start point, in which he is found in the car Porsche Cayenne II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram jump start point (1 of 6)
1 2 LIN TERM 30
4.8L 3.6L
BATTERY SENSOR (ON VEHICLE ELECTRICAL SYSTEM BATTERY)
BLK WIRE
BLU WIRE
DC/DC CONVERTER (RIGHT REAR OF ENGINE COMPT)
GATEWAY CONTROL UNIT (LEFT END OF DASH)
GENERATOR
JUMP START POINT
LIN
LIN 1
MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
STARTER
VEHICLE ELECTRICAL SYSTEM BATTERY
Go to component -> 3.6l, charging circuit -> JUMP START POINT
Wiring diagram jump start point (2 of 6)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 LIN TERM 30
1 2 LIN TERM 30
1 5 2 TERM 31 TERM 15 GPA
2 5 P/N POSITION SW PA
22 34 46 SW PA CAN LO CAN HI
4 3 INTERLOCK EPB
A/T
AUTOMATIC TRANSMISSION
BATTERY SENSOR (ON VEHICLE ELECTRICAL SYSTEM BATTERY)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CLUTCH
CLUTCH SENSOR
COMPUTER DATA LINES SYSTEM
DC/DC CONVERTER (RIGHT REAR OF ENGINE COMPT)
DME CONTROL UNIT (RIGHT REAR ENGINE COMPT)
ELECTRONIC IGNITION LOCK
EPB CONTROL UNIT (RIGHT SIDE OF CARGO AREA)
FRONT BCM (LEFT SIDE OF DASH)
FUSE
GENERATOR
GP-25 (UNDER DRIVER'S SEAT)
GRY/BRN WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED
HOT W/ TERMINAL 15 RELAY ENERGIZED PLENUM PANEL MAXI FUSE FUSE BOX
JUMP START POINT
LEFT FUSE BOX FUSE (LEFT SIDE OF DASH)
LIN
M/T
MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
SENS GND SWITCH 6 SWITCH 2
STARTER
STARTER RELAY 1 (E-BOX RELAY SUPPORT 2)
STARTER RELAY 2 (E-BOX INSTRUMENT CLUSTER MODULE)
STEERING COLUMN LOCK
SWITCH 5 SWITCH 4 SWITCH 3 SWITCH 1 PWR GND WITHDRAWAL LOCK
TERM 50
TRANSMISSION CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT)
VEHICLE ELECTRICAL SYSTEM BATTERY
VIO WIRE
VIO/YEL WIRE
WHT/RED WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> 3.6l, starting circuit -> JUMP START POINT
Wiring diagram jump start point (3 of 6)
1 2 LIN TERM 30
4.8L 3.6L
BATTERY SENSOR (ON VEHICLE ELECTRICAL SYSTEM BATTERY)
BLK WIRE
BLU WIRE
DC/DC CONVERTER (RIGHT REAR OF ENGINE COMPT)
GATEWAY CONTROL UNIT (LEFT END OF DASH)
GENERATOR
JUMP START POINT
LIN
LIN 1
MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
STARTER
VEHICLE ELECTRICAL SYSTEM BATTERY
Go to component -> 4.8l, charging circuit -> JUMP START POINT
Wiring diagram jump start point (4 of 6)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 LIN TERM 30
1 2 LIN TERM 30
2 5 P/N POSITION SW PA
22 34 46 SW PA CAN LO CAN HI
8 41 54 29 STR RLY CAN DRIVE LO CAN DRIVE HI START RELEASE/PARK/NEUTRAL
AUTOMATIC TRANSMISSION
BATTERY SENSOR (ON VEHICLE ELECTRICAL SYSTEM BATTERY)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DC/DC CONVERTER
DIA TERM 50 RLY
DME CONTROL UNIT (RIGHT REAR ENGINE COMPARTMENT)
ELECTRONIC IGNITION LOCK
FRONT BCM (LEFT SIDE OF DASH)
FUSE
GENERATOR
GP-25 (UNDER DRIVER'S SEAT)
GRN/WHT WIRE
GRY/BRN WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED PLENUM PANEL MAXI FUSE FUSE BOX
JUMP START POINT
LEFT FUSE BOX FUSE (LEFT SIDE OF DASH)
LIN
MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
SENS GND SWITCH 6 SWITCH 2
STARTER
STARTER RELAY 2 (E-BOX INSTRUMENT CLUSTER MODULE)
SWITCH 5 SWITCH 4 SWITCH 3 SWITCH 1 PWR GND WITHDRAWAL LOCK
TRANSMISSION CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT)
VEHICLE ELECTRICAL SYSTEM BATTERY
VIO WIRE
VIO/YEL WIRE
WHT/BLK WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> 4.8l, starting circuit -> JUMP START POINT
Wiring diagram jump start point (5 of 6)
1 2 LIN TERM 30
4.8L 3.6L
BATTERY SENSOR (ON VEHICLE ELECTRICAL SYSTEM BATTERY)
BLK WIRE
BLU WIRE
DC/DC CONVERTER (RIGHT REAR OF ENGINE COMPT)
GATEWAY CONTROL UNIT (LEFT END OF DASH)
GENERATOR
JUMP START POINT
LIN
LIN 1
MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
STARTER
VEHICLE ELECTRICAL SYSTEM BATTERY
Go to component -> 4.8l twin turbo, charging circuit -> JUMP START POINT
Wiring diagram jump start point (6 of 6)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 LIN TERM 30
1 2 LIN TERM 30
2 5 P/N POSITION SW PA
22 34 46 SW PA CAN LO CAN HI
8 41 54 29 STR RLY CAN DRIVE LO CAN DRIVE HI START RELEASE/PARK/NEUTRAL
AUTOMATIC TRANSMISSION
BATTERY SENSOR (ON VEHICLE ELECTRICAL SYSTEM BATTERY)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DC/DC CONVERTER
DIA TERM 50 RLY
DME CONTROL UNIT (RIGHT REAR ENGINE COMPARTMENT)
ELECTRONIC IGNITION LOCK
FRONT BCM (LEFT SIDE OF DASH)
FUSE
GENERATOR
GP-25 (UNDER DRIVER'S SEAT)
GRN/WHT WIRE
GRY/BRN WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED PLENUM PANEL MAXI FUSE FUSE BOX
JUMP START POINT
LEFT FUSE BOX FUSE (LEFT SIDE OF DASH)
LIN
MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
SENS GND SWITCH 6 SWITCH 2
STARTER
STARTER RELAY 2 (E-BOX INSTRUMENT CLUSTER MODULE)
SWITCH 5 SWITCH 4 SWITCH 3 SWITCH 1 PWR GND WITHDRAWAL LOCK
TRANSMISSION CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT)
VEHICLE ELECTRICAL SYSTEM BATTERY
VIO WIRE
VIO/YEL WIRE
WHT/BLK WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> 4.8l twin turbo, starting circuit -> JUMP START POINT
