Porsche Cayenne II (2010-2014) hi volt minus shield Wiring diagram
This page shows the only wiring diagram for the component.hi volt minus shield, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hi volt minus shield (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 CRASH SIG CRASH GND PILOTLINE OUT
1 2 3 4 CAN HYBRID LOW CAN HYBRID HI CAN DRIVE LOW CAN DRIVE HI
BLK WIRE
BLK/RED WIRE
BLOWER
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/YEL WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM GP-1 (BEHIND LEFT HEADLIGHT)
CONTACT 2 IN
CONTACT 2 OUT
ENGINE COMPT)
EQUALISATION
FAN RELAY PILOTLINE IN FAN 1 PWM FAN 1 FEEDBACK FAN 2 PWM FAN 2 FEEDBACK
FEEDBACK
FUSE
GP-41 (NEAR LEFT TAILLIGHT)
GP-5 (LEFT FRONT OF
GP-MB HV (LEFT REAR OF VEHICLE, NEAR BATTERY)
GRN/BLK WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY/RED WIRE
GRY/VIO WIRE
HI VOLT MINUS SHIELD
HI VOLT PLUS SHIELD
HIGH VOLTAGE BATTERY SYSTEM (UNDER LUGGAGE COMPT)
HOT AT ALL TIMES
HOT AT ALL TIMES JUMP FUSE POINT
LEFT BATTERY FAN (LEFT SIDE OF BATTERY COMPT)
LEFT TOP LOADER BATTERY COOLING RELAY
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/WHT WIRE
PWM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RIGHT BATTERY FAN (RIGHT SIDE OF BATTERY COMPT)
SPINDLE ACTUATOR
SUPPLEMENTAL RESTRAINTS SYSTEM
TERM 15
TERM 30
TERM 30 TERM 31 TERM 15
TERM 31
VIO WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 3.0l hybrid (8 of 9) -> HI VOLT MINUS SHIELD
