Porsche Cayenne II (2010-2014) heated rear window wiring diagram
This page shows the only wiring diagram for the component.heated rear window, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
heated rear window wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
FUSE 26
GP-23 (LEFT SIDE OF DASH)
GP-45 (TOP LEFT SIDE OF LIFTGATE)
GRY/WHT WIRE
HEATED REAR WINDOW
HOT W/ TERMINAL
LEFT REAR WINDOW BLOCKING CIRCUIT
REAR BCM (RIGHT SIDE OF REAR COMPT)
REAR WINDOW HEATER RELAY (ON LEFT TOP LOADER RELAY CARRIER)
RED/WHT WIRE
RED/YEL WIRE
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
RR WINDOW HEATED RLY
RR WINDOW SENS
Go to component -> Defogger circuit -> HEATED REAR WINDOW
