Porsche Cayenne II (2010-2014) front passenger seat cushion vent motor Wiring diagram

1 2 3 4 SEAT DEPTH ADJ 1 SEAT DEPTH ADJ 2 HALL SENS - HALL SENS + 1 2 AFT ADJ 1 AFT ADJ 2 1 2 ANGLE ADJ 1 ANGLE ADJ 2 1 2 PWM TERMINAL 31 2 1 HEIGHT ADJ 2 HEIGHT ADJ 1 2 3 1 TERMINAL 31 TERMINAL 30 PWM A/C CONTROL UNIT BLK/YEL WIRE BLU WIRE BRN WIRE BRN/VIO WIRE FRONT PASSENGER SEAT BACKREST VENT MOTOR FRONT PASSENGER SEAT CUSHION VENT MOTOR GP-26 (UNDER FRONT PASSENGER'S SEAT) GRN WIRE GRN/BLU WIRE PIPE FRAME SERVO MOTOR RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RH SEAT VENT SEAT DEPTH ADJUSTMENT MOTOR TERMINAL 30 VIO WIRE WHT WIRE WHT/YEL WIRE
