Porsche Cayenne II (2010-2014) front bluetooth charging tray Wiring diagram
This page shows the only wiring diagram for the component.front bluetooth charging tray, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front bluetooth charging tray (1 of 1)
A/C CONTROL UNIT
AIR QUALITY SENSOR
AUTOMATIC TRANSMISSION
BATTERY SENSOR
BCM
BRN WIRE
CENTER CONSOLE CIGAR LIGHTER
CENTER CONSOLE STORAGE BIN SOCKET
CENTRE CONSOLE REAR PLUG SOCKET 1
CHASSIS CONTROL SWITCH
COMPASS
EXHAUST FLAP VALVE
FRESH AIR FAN MOTOR
FROM GP-20 (DIAGRAM 3 OF 6)
FROM SUPER CHARGER LEVEL CONTROL (DIAGRAM 5 OF 6)
FRONT BLUETOOTH CHARGING TRAY
FRONT LIGHT ASHTRAY
FRONT REAR SEAT ENTERTAINMENT
GLOVE BOX SWITCH
GP-22 (RIGHT SIDE OF DASH)
GP-23 (LEFT SIDE OF DASH) REAR DIFFERENTIAL LOCK CONTROL UNIT
GP-24 (FRONT OF CENTER CONSOLE)
GP-25 (UNDER DRIVER'S SEAT)
GP-26 (UNDER FRONT PASSENGER'S SEAT)
HAND BRAKE SWITCH
IGNITION LOCK LIGHT
INSTRUMENT CLUSTER
IRU DEACTIVATION BUTTON
LEFT B-PILLAR AIR VENT LIGHTING
LEFT COCKPIT AIR VENT LIGHTING
LEFT COCKPIT CENTER AIR VENT LIGHTING
LEFT REAR CENTER AIR VENT LIGHTING
LEFT TOP LOADER (TWO-TONE HORNS RELAY)
LEFT TOP LOADER REAR WINDOW HEATER RELAY
MOBILE PHONE CHARGING TRAY
ODDMENTS TRAY LIGHTING
PDCC ALL WHEEL CONTROL DRIVE UNIT CONTROL UNIT
PTC HEATER
REAR OPERATING, A/C UNIT
REAR REVERSING LIGHT/ FOG LIGHT
RIGHT B-PILLAR AIR VENT LIGHTING
RIGHT COCKPIT AIR VENT LIGHTING
RIGHT COCKPIT CENTER AIR VENT LIGHTING
RIGHT REAR CENTER AIR VENT LIGHTING
SELECTOR LEVER CONTROL UNIT
STEERING ELECTRONIC COLUMN IGNITION LOCK LOCK
SUN SENSOR
TRANSMISSION CONTROL UNIT
TRANSMISSION OIL SHUTOFF VALVE
Go to component -> Ground distribution circuit (4 of 6) -> FRONT BLUETOOTH CHARGING TRAY
