Porsche Cayenne II (2010-2014) driver seat cushion ventilation motor Wiring diagrams
This page contains all the electrical diagrams for the component. driver seat cushion ventilation motor, in which he is found in the car Porsche Cayenne II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver seat cushion ventilation motor (1 of 3)
1 2 3 4 SEAT DEPTH ADJ 1 SEAT DEPTH ADJ 2 HALL SENS - HALL SENS +
1 2 HEIGHT ADJ 1 HEIGHT ADJ 2
1 2 PWM TERMINAL 31
2 1 AFT ADJ 2 AFT ADJ 1
2 1 ANGLE ADJ 2 ANGLE ADJ 1
2 3 1 TERMINAL 31 TERMINAL 30 PWM
A/C CONTROL UNIT
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/VIO WIRE
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER'S SEAT BACKREST VENT MOTOR
GP-31 (BASE OF LEFT "B" PILLAR)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
LH SEAT VENT
PIPE FRAME SERVO MOTOR
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
SEAT DEPTH ADJUSTMENT MOTOR
TERMINAL 30
VIO WIRE
WHT WIRE
WHT/YEL WIRE
Go to component -> Driver"s memory seat circuit (2 of 2) -> DRIVER SEAT CUSHION VENTILATION MOTOR
Wiring diagram driver seat cushion ventilation motor (2 of 3)
BRN WIRE
DRIVER SEAT ADJUSTMENT OUTPUT CONTROL UNIT
DRIVER SEAT BACKREST VENTILATION MOTOR
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER SEAT SEAT FOOTWELL CONTROL LIGHT UNIT
FRONT PASSENGER'S SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER'S SEAT FOOTWELL LIGHT
FUEL PUMP SYSTEM CONTROL UNIT
GP-28 (RIGHT END OF DASH)
GP-30 (BASE OF RIGHT "B" PILLAR)
GP-31 (BASE OF LEFT "B" PILLAR)
GP-34 (RIGHT FRONT OF REAR COMPT)
LEFT FRONT REAR SEAT ENTERTAINMENT
LEFT FRONT SEAT BACKREST HEATING ELEMENT
LEFT REAR DOOR CONTROL UNIT
LEFT REAR DOOR SILL LIGHTING
LEFT REAR LEFT FRONT SEAT SEAT CUSHION CUSHION HEATING HEATING ELEMENT ELEMENT
LEFT REAR OUT SIDE DOOR LEFT REAR HANDLE DOOR LOCK SWITCH SLOT
MAIN FUSE BOX
PCM
PDK CONTROL UNIT
RADIO, AMPLIFIER
REAR DIFFERENTIAL LOCK CONTROL UNIT
RIGHT FRONT LEFT FRONT DOOR SILL DOOR SILL LIGHTING LIGHTING
RIGHT FRONT SEAT BACKREST HEATING ELEMENT
RIGHT FRONT SEAT CUSHION HEATING ELEMENT
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR DOOR LOCK SLOT
RIGHT REAR DOOR SILL LIGHTING
RIGHT REAR OUT SIDE DOOR HANDLE SWITCH
RIGHT REAR SEAT CUSHION HEATING ELEMENT
SUPER CHARGER LEVEL CONTROL
TANK SYSTEM
TO GP-26 (DIAGRAM 4 OF 6)
TRANSMISSION OIL PUMP DRIVER
W/ MEMORY
WHT WIRE
Go to component -> Ground distribution circuit (5 of 6) -> DRIVER SEAT CUSHION VENTILATION MOTOR
Wiring diagram driver seat cushion ventilation motor (3 of 3)
3.0L HYBRID
AIR QUALITY SENSOR
ANTI-DAZZLE INTERIOR MIRROR
AUTOMATIC TRANSMISSION
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER'S SEAT BACKREST VENT MOTOR
ELECTRIC A/C COMPRESSOR
ELECTRONIC POWER DRIVE
EPB PSM CONTROL CONTROL UNIT UNIT
FROM MAIN FUSE BOX, TERMINAL 15 RELAY (DIAGRAM 1 OF 8)
FRONT PASSENGER SEAT BACKREST VENT MOTOR
FRONT PASSENGER SEAT CUSHION VENTILATION MOTOR
FUSE
FUSE 43 FUSE
FUSE 44
FUSE 46 FUSE 51 FUSE 52
FUSE 53
FUSE 54
FUSE FUSE
FUSE FUSE FUSE
LANE CHANGE ASSISTANT SLAVE
LANE CHANGE REAR ASSISTANT WINDOW MASTER MODULE
LEFT FUSE BOX (LEFT SIDE OF DASH)
LEFT HEADLIGHT
LEFT TAIL LIGHT ASSEMBLY
PDCC CONTROL UNIT
POWER STEERING PUMP
RED/GRN WIRE
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
RIGHT HEADLIGHT
SPINDLE ACTUATOR
STEERING COLUMN SWITCHING MODULE
SUN RIGHT SENSOR TAILLIGHT ASSEMBLY
TO LEFT FUSE BOX, FUSE 47 (DIAGRAM 7 OF 8)
TO PLENUM PANEL FUSE BOX, FUSE 1 (DIAGRAM 2 OF 8)
TRANSMISSION CONTROL UNIT RIGHT HEADLIGHT
VIO WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (6 of 8) -> DRIVER SEAT CUSHION VENTILATION MOTOR
