Porsche Cayenne II (2010-2014) button term 15 term 31 Wiring diagram
This page shows the only wiring diagram for the component.button term 15 term 31, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram button term 15 term 31 (1 of 1)
1 2 3 4 CAN LOW 2 CAN HIGH 2 FUN LED
10 11 12 TERM 31
BRN WIRE
BRN/GRY WIRE
BUTTON TERM 15 TERM 31
CAN HIGH 1
CAN HIGH 2
CAN LOW 1 6 7 8 9 10 11 12
CAN LOW 2 SWA LED, DS+
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MIRROR
DRIVER'S DOOR BUTTON MODULE
FUNCTION IND SWA
FUSE
GP-41 (NEAR LEFT TAILLIGHT)
HOT W/ TERMINAL 15 RELAY ENERGIZED
LANE CHANGE ASSISTANT MASTER (LEFT END OF REAR BUMPER)
LANE CHANGE ASSISTANT SLAVE (RIGHT END OF REAR BUMPER)
LEFT FUSE BOX (LEFT SIDE OF DASH)
ORG/BLU WIRE
ORG/BRN WIRE
PASSENGER DOOR MIRROR
SWA BUTTON
SWA LED, PS+ TERM 15
SWA LED-
VIO/BLK WIRE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/RED WIRE
WHT WIRE
YEL/RED WIRE
Go to component -> Lane change assistance circuit -> BUTTON TERM 15 TERM 31
