Porsche Cayenne II (2010-2014) adjustment back adjustment fwd Wiring diagrams
This page contains all the electrical diagrams for the component. adjustment back adjustment fwd, in which he is found in the car Porsche Cayenne II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
adjustment back adjustment fwd wiring diagram (1 of 2)
1 2 3 4 AFT ADJ 1 AFT ADJ 2
1 2 3 4 ANGLE ADJ 1 ANGLE ADJ 2
1 2 3 4 HEIGHT ADJ 1 HEIGHT ADJ 2
ADJUSTMENT BACK ADJUSTMENT FWD
BACKREST ADJ 2 BACKREST ADJ 1
BLU WIRE
BRN WIRE
DRIVER SEAT ADJUSTMENT OPTICAL CONTROL UNIT
DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR
FUSE
GRN WIRE
GRY WIRE
HOT W/
LEFT FUSE BOX (LEFT SIDE OF DASH)
PIPE FRAME SERVO MOTOR
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RELAY ENERGIZED
VIO WIRE
Go to component -> Driver power seat circuit -> ADJUSTMENT BACK ADJUSTMENT FWD
adjustment back adjustment fwd wiring diagram (2 of 2)
1 2 3 4 AFT ADJ 1 AFT ADJ 2
2 1 3 4 ANGLE ADJ 2 ANGLE ADJ 1
2 1 3 4 HEIGHT ADJ 2 HEIGHT ADJ 1
ADJUSTMENT BACK ADJUSTMENT FWD
BACKREST ADJ 2 BACKREST ADJ 1
BLU WIRE
BRN WIRE
FRONT PASSENGER SEAT ADJUSTMENT OPTICAL CONTROL UNIT
FRONT PASSENGER SEAT BACKREST ADJUSTMENT MOTOR
FUSE
GP-26 (UNDER FRONT PASSENGER'S SEAT)
GRN WIRE
GRY WIRE
HOT W/
PIPE FRAME SERVO MOTOR
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
VIO WIRE
Go to component -> Passenger power seat circuit -> ADJUSTMENT BACK ADJUSTMENT FWD
