Porsche Cayenne II (2010-2014) actuation phase u sig phase v terminal 30 phase w Wiring diagram
This page shows the only wiring diagram for the component.actuation phase u sig phase v terminal 30 phase w, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram actuation phase u sig phase v terminal 30 phase w (1 of 1)
1 2 3 4 5 SIGNAL W SIGNAL V SIGNAL U DATA SIGNAL GND
1 2 3 PHASE W PHASE U PHASE V
11 12 SHIFTLOCK + TERM 31
2 1 TEMP - TEMP +
3 2 1 PHASE V PHASE U PHASE W
3 2 1 PHASE W PHASE U PHASE V
5 4 3 2 1 GND DATA SIGNAL SIGNAL U SIGNAL V SIGNAL W
ACTUATION PHASE U SIG PHASE V TERMINAL 30 PHASE W
BCM CONTROL UNIT
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
CAN L
COMPUTER DATA LINES SYSTEM
EXCEPT HYBRID
GND TERM 30 SIG ACTUATION
GP-22 (RIGHT SIDE OF DASH)
GP-30 (BASE OF RIGHT "B" PILLAR)
GRN WIRE
GRY/WHT WIRE
INSTRUMENT CLUSTER
LEFT TOP LOADER (EXCEPT HYBRID)
LEFT TOP LOADER (HYBRID)
ORG/BRN WIRE
ORG/VIO WIRE
PARK TERMINAL 31 TERMINAL 30 POSITION POSITION
POSI
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
SELECTOR LEVER
SELECTOR LEVER CONTROL UNIT (UNDER CENTER CONSOLE)
SPLY
TION
TRANSMISSION OIL PUMP (EXCEPT HYBRID)
TRANSMISSION OIL PUMP (HYBRID)
TRANSMISSION OIL PUMP DRIVER (HYBRID) (RIGHT REAR OF ENGINE COMP)
TRANSMISSION OIL PUMP RELAY
VIO WIRE
VIO/WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> A/t circuit (2 of 2) -> ACTUATION PHASE U SIG PHASE V TERMINAL 30 PHASE W
