Porsche Cayenne II (2010-2014) a/c power liftgate control control unit unit Wiring diagram
This page shows the only wiring diagram for the component.a/c power liftgate control control unit unit, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c power liftgate control control unit unit (1 of 1)
3.0L HYBRID
3.6L
A/C PCM RADIO CONTROL UNIT
A/C POWER LIFTGATE CONTROL CONTROL UNIT UNIT
BATTERY COOLING RELAY
BATTERY ELECTRONIC POWER COOLING RELAY DRIVE
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
CLUTCH SENSOR (M/T)
CONTROL UNIT)
DIAGNOSTIC PLUG SOCKET
FROM LEFT FUSE BOX, FUSE 51 (DIAGRAM 6 OF 8)
FROM MAIN FUSE BOX FUSE 3 (DIAGRAM 1 OF 8)
FROM MAIN FUSE BOX, FUSE 5 (DIAGRAM 1 OF 8)
FROM MAIN FUSE BOX, FUSE 8 (DIAGRAM 1 OF 8)
FUSE
FUSE 22 FUSE 23
FUSE 24
FUSE 25
FUSE 26 DASH)
FUSE 38
FUSE 39
FUSE 40
FUSE 41
FUSE FUSE FUSE
FUSE FUSE FUSE FUSE FUSE
GATEWAY CONTROL UNIT
GRY/VIO WIRE
HAND BRAKE SWITCH
HIGH-VOLT BATTERY SYSTEM
INSTRUMENT BACKUP CLUSTER CAMERA CONTROL UNIT
LEFT FUSE BOX (LEFT SIDE OF DASH)
LEFT REAR DOOR CONTROL UNIT
PARKASSIST HOMELINK CONTROL CONTROL UNIT UNIT
REAR FAN MOTOR
REAR OPERATING, A/C UNIT
REAR WINDOW HEATER RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
REFRIGERANT PRESSURE SENSOR
RIGHT FUSE BOX (RIGHT SIDE OF
SPINDLE ACTUATOR
STARTER RELAY 2 STARTER RELAY 1
STEERING COMPASS COLUMN SWITCHING MODULE
TELEVISION TUNER
TO DC/DC CONVERTER (DIAGRAM 8 OF 8)
TO DC/DC REAR CONVERTER OPERATING, (DIAGRAM A/C UNIT 8 OF 8)
W/O W/ MEMORY MEMORY
WHT WIRE
Go to component -> Power distribution circuit (7 of 8) -> A/C POWER LIFTGATE CONTROL CONTROL UNIT UNIT
