Porsche Cayenne II (2010-2014) 6 4 5 1 2 seat temp left signal gnd seta temp right Wiring diagram
This page shows the only wiring diagram for the component.6 4 5 1 2 seat temp left signal gnd seta temp right, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 6 4 5 1 2 seat temp left signal gnd seta temp right (1 of 1)
1 2 3 4 NTC + HEATER + HEATER - NTC -
1 2 GND BACKREST HEATING ELEMENT
1 2 GND BOLSTER HEATER
1 2 GND BOLSTER HTR
1 2 GND HEATING ELEMENT
1 2 HEATER - HEATER +
14 15 16 TEMP SENS RH SIG GND SEAT TEMP
2 3 LEFT HTR SEAT RIGHT HTR SEAT
3 4 NTC + NTC -
6 4 5 1 2 SEAT TEMP LEFT SIGNAL GND SETA TEMP RIGHT
A/C CONTROL UNIT
BACKREST 1 2 GND SIDE BOLSTER
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
FUSE
GP-22 (RIGHT SIDE OF DASH)
GP-26 (UNDER FRONT PASSENGER'S SEAT)
GP-30 (BASE OF RIGHT "B" PILLAR)
GP-31 (BASE OF LEFT "B" PILLAR)
HEATER
HEATING
HOT W/
LEFT FRONT SEAT BACKREST HEATING ELEMENT
LEFT FRONT SEAT CUSHION HEATING ELEMENT
LEFT REAR BACKREST BOLSTER HEATING ELEMENT
LEFT REAR SEAT BACKREST HEATING ELEMENT
LEFT REAR SEAT CUSHION HEATING ELEMENT
LEFT REAR SIDE BOLSTER HEATING ELEMENT
REAR OPERATING, A/C UNIT
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT SEAT BACKREST HEATING ELEMENT
RIGHT FRONT SEAT CUSHION HEATING ELEMENT
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
RIGHT REAR BACKREST BOLSTER HEATING ELEMENT
RIGHT REAR SEAT BACKREST HEATING ELEMENT
RIGHT REAR SEAT CUSHION HEATING ELEMENT
RIGHT REAR SIDE BOLSTER HEATING ELEMENT
SENS LH SEAT HTR LH SEAT HTR RH 2 3
TERMINAL 31
WHT/YEL WIRE
YEL WIRE
Go to component -> Rear seat heater circuit -> 6 4 5 1 2 SEAT TEMP LEFT SIGNAL GND SETA TEMP RIGHT
