Porsche Cayenne II (2010-2014) 25 24 mirror, adjustment mirror, adjustment Wiring diagram
This page shows the only wiring diagram for the component.25 24 mirror, adjustment mirror, adjustment, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 25 24 mirror, adjustment mirror, adjustment (1 of 1)
1 2 3 4 CAMERA SUPPLY CAMERA GROUND SWA LED + SWA LED -
1 2 CAMERA OUTPUT CAMERA SHIELD
2 8 SWA LED -
25 24 MIRROR, ADJUSTMENT MIRROR, ADJUSTMENT
3 6 MIRROR, ADJUSTMENT CHANGEOVER SWITCH
AUTO ANTI-DAZZLING MIRROR CIRCUIT
BLK WIRE
BRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
DRIVER DOOR CONTROL UNIT
DRIVER DOOR MIRROR
DRIVER'S DOOR BUTTON MODULE
FUSE 16
GRY WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT FUSE BOX
PASSENGER DOOR CONTROL UNIT
PASSENGER DOOR MIRROR
POTI ENGINE 1 POTENTIOMETER + MIRROR HEATING POTI ENGINE 2
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT LANE CHANGE ASSISTANT (LEFT END OF REAR BUMPER)
SWA LED + SWA LED -
SWA LED, PS+
SWA LED-
VIO WIRE
VIO/BLK WIRE
VIO/GRN WIRE
VIO/RED WIRE
WHT WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Power mirrors circuit -> 25 24 MIRROR, ADJUSTMENT MIRROR, ADJUSTMENT
