Porsche Cayenne II (2010-2014) 24 2 reversing light right reversing light left Wiring diagram
This page shows the only wiring diagram for the component.24 2 reversing light right reversing light left, which is found in the car Porsche Cayenne II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 24 2 reversing light right reversing light left (1 of 1)
24 2 REVERSING LIGHT RIGHT REVERSING LIGHT LEFT
42 34 CAN HIGH CAN LOW
AUTOMATIC TRANSMISSION
BACK/UP LT SW
BACKUP LIGHT
BACKUP SIGNAL
BLU/BLK WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DME CONTROL UNIT (RIGHT REAR ENGINE COMPT)
FUSE 31
GP-26 (UNDER FRONT PASSENGER'S SEAT)
GP-40 (NEAR RIGHT TAILLIGHT)
GP-41 (NEAR LEFT TAILLIGHT)
GRY/GRN WIRE
HOT AT ALL TIMES
INTERLOCK -
LEFT REAR LID TAIL LIGHT UNIT
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PARK/NEUTRAL POSITION
REAR BCM (RIGHT SIDE OF REAR COMPT)
RED/BLU WIRE
RED/WHT WIRE
REVERSING LIGHT/ REAR FOG LIGHT
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
RIGHT REAR LID TAIL LIGHT UNIT
SWITCH PA
TERM 30
TERM 31
TRANSMISSION CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT)
YEL/VIO WIRE
Go to component -> Backup lamps circuit -> 24 2 REVERSING LIGHT RIGHT REVERSING LIGHT LEFT
