Porsche Cayenne II (2010-2014) 17 3 rear lid button outer warning lig rear lid Wiring diagram

1 2 SIG SIG 1 4 CLOSING AID MOTOR CLOSED CLOSING AID MOTOR OPEN 17 3 REAR LID BUTTON OUTER WARNING LIG REAR LID 39 38 30 REAR LID CLOSING AID ROTARY LATCH REAR LID CLOSING AID PAWL DRIVE SW ACUTATOR TANK COVER CLOSE ACUTATOR TANK COVER OPEN BRN WIRE BRN/YEL WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM FRONT BODY CONTROL MODULE (LEFT SIDE OF DASH) FUSE 31 (LEFT SIDE OF DASH) GRY/BLU WIRE HOT AT ALL TIMES LEFT FUSE BOX OPEN REAR LID HANDLE ORG/BRN WIRE ORG/GRN WIRE REAR BODY CONTROL MODULE (RIGHT SIDE OF REAR COMPT) RED/BRN WIRE RED/WHT WIRE RIGHT REAR LID WARNING LIGHT TAILGATE LOCK MOTOR TANK COVER ACTUATOR W/O DRIVE SWITCH W/ DRIVE SWITCH WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE
