Porsche Cayenne II (2010-2014) 10 11 rear dual washer pump front dual washer pump Wiring diagram

1 2 FRONT REAR 1 2 TERM 15 TERM 31 10 11 REAR DUAL WASHER PUMP FRONT DUAL WASHER PUMP 2 1 SENSOR TERM 31 2 3 4 INTERVAL WIPE/WASH TERM 15 2 3 TERM 31 LIN 30 33 WASHER FLUID LEVEL LIN 1 39 35 REAR WIPER WASH REAR WIPER INTREVAL 40 7 SENSOR GND TERM 15 HEATED SPRAY JETS BCM BLK WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE DUAL WASHING PUMP FRONT WIPER MOTOR GP-13 (REAR CENTER OF ENGINE COMPT) GP-21 (LEFT KICK PANEL) GP-6 (RIGHT FRONT OF ENGINE COMPT) GRN/BLU WIRE GRN/RED WIRE GRY/WHT WIRE HOT W/ HOT W/ TERMINAL 15 RELAY ENERGIZED FUSE 52 LEFT FRONT HEATED SPRAY JET LEFT FUSE BOX (LEFT SIDE OF DASH) LIN RAIN SENSOR REAR WINDOW MODULE RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED FUSE 4 RELAY ENERGIZED FUSE 9 RIGHT FRONT HEATED SPRAY JET ROTARY LIGHT SWITCH SUPPLY TERM 30 TERM 31 VIO/GRN WIRE WASHER FLUID WASHER FLUID LEVEL SENSOR YEL/RED WIRE
