Porsche Cayenne I facelift (2007-2010) signal signal signal Wiring diagram

1 2 3 4 5 6 FRONT FOG LIGHT,RIGHT 1 2 3 4 5 6 TURN SIGNAL,LEFT FRONT TERMINAL 31 LOW BEAM,LEFT 1 2 3 4 TWO-TONE HORN TERMINAL 30 TWO-TONE HORN TERMINAL 30 TERMINAL 30 RIGHT 1 2 TERMINAL 30 LEFT TERMINAL 30 ADDITIONAL HIGH BEAM HEADLIGHT TURN SIGNAL,LEFT REAR BLK/WHT WIRE BLU/BRN WIRE BLU/WHT WIRE BRN WIRE FUSE 16 FUSE 20 FUSE 35 FUSE 17 FUSE 19 FUSE 8 FUSE 9 GRN/RED WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/WHT WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM INTERIOR LIGHTS, HEADLIGHTS SYSTEMS HIGH BEAM,LEFT HORNS SYSTEM HOT AT ALL TIMES LEFT FUSE BOX (UNDER LEFT SIDE OF DASH) MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY) ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH) SIDE MARKER LIGHT,RIGHT SIGNAL SIGNAL SIGNAL TERMINAL 30 TERMINAL 31 VIO WIRE VIO/GRN WIRE WHT/BLK WIRE WHT/YEL WIRE YEL/BLK WIRE
