Porsche Cayenne I facelift (2007-2010) sensor ground fuel pmp rly 1 actuation fan wiring diagram

ACTUATION FAN AIR CONDITIONING SYSTEM BLK WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE CLUTCH SWITCH COOLING FANS SYSTEM CRUISE CONTROL E-BOX E-BOX (LEFT FUSE 15 SIDE OF WATER BOX) FUEL PMP RLY 2 FUSE 13 FUSE 14 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND SIGNAL GRY GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES TRANSFER SOCKET LEFT OXYGEN SENSOR 1 (BEFORE CATALYTIC CONVERTER) LEFT OXYGEN SENSOR 2 (BEHIND CATALYTIC CONVERTER) MOTOR CONTROL UNIT (RIGHT REAR OF ENGINE COMPT) PEDAL VALUE SENSOR (ON ACCELERATOR PEDAL) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT OXYGEN SENSOR 1 (BEFORE CATALYTIC CONVERTER) RIGHT OXYGEN SENSOR 1 (BEHIND CATALYTIC CONVERTER) SENSOR GROUND FUEL PMP RLY 1 ACTUATION FAN SYSTEM TANK LEAK DIAG TEMPERATURE SENSOR VIO WIRE VIO/RED WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/VIO WIRE
